Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 3500/72M-01-00 |
| Manufacturer | Bently Nevada |
| Series | 3500 Machinery Protection |
| Module Type | Recip Rod Position Monitor |
| Part Number | 176449-08 |
| Channels | 2 independent rod position channels |
| Input Signal | Proximity probe or rod position transducer |
| Measurement Range | ±25 mm typical |
| Resolution | 0.01 mm |
| Accuracy | ±0.05 mm |
| Output | 4–20 mA analog per channel |
| Connectivity | Compatible with 3500 system backplane |
| Mounting | Standard 3500 rack module format |
| Dimensions | 230 mm (L) x 160 mm (W) x 40 mm (H) |
| Weight | 1.5 kg (3.3 lbs) |
| Operating Temperature | -20°C to +70°C (-4°F to +158°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Humidity | 5–95%, non-condensing |
| Power Requirements | Supplied via 3500 system rack, 24 VDC nominal |
| Environmental Rating | Shock-resistant, vibration-resistant, industrial-grade |
| Diagnostic Features | LED indicators for channel status and system health |
FAQ
A1: Yes, it integrates fully with standard 3500 system racks.
Q2: What is the measurement range for rod position?
A2: The module measures ±25 mm with a resolution of 0.01 mm.
Q3: Does it provide analog outputs?
A3: Yes, each channel provides 4–20 mA analog output signals.
Q4: Can it handle harsh industrial environments?
A4: Yes, it is vibration-resistant, shock-resistant, and operates from -20°C to +70°C.
Q5: What is the typical lead time for delivery?
A5: Orders usually ship within 3–14 days depending on order size and location.
Q6: Is there a return policy for defective products?
A6: Yes, returns are accepted within 30 days for quality-related issues.
