Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 3500/70M-01-00 |
| Manufacturer | Bently Nevada |
| Series | 3500 Machinery Protection |
| Module Type | Recip Impulse Velocity Monitor |
| Part Number | 176449-09 |
| Channels | 2 independent velocity channels |
| Input Signal | Proximity probe or velocity transducer signals |
| Measurement Range | 0–200 mm/s peak velocity |
| Frequency Response | 0.5 Hz to 10 kHz |
| Sensitivity | 50 mV/mm/s nominal |
| Accuracy | ±2% of reading |
| Output | 4–20 mA analog signals per channel |
| Connectivity | Compatible with 3500 system backplane |
| Mounting | Standard 3500 rack module format |
| Dimensions | 230 mm (L) x 160 mm (W) x 40 mm (H) |
| Weight | 1.6 kg (3.5 lbs) |
| Operating Temperature | -20°C to +70°C (-4°F to +158°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Humidity | 5–95%, non-condensing |
| Power Requirements | Supplied via 3500 system rack, 24 VDC nominal |
| Environmental Rating | Shock-resistant, vibration-resistant, industrial-grade |
| Compliance | CE, UL, RoHS certified |
| Diagnostic Features | LED indicators for channel status and health |
