Overview
Moreover, this module plays a central role within the Bently Nevada 3500 Machinery Protection Series for accurate vibration analysis.
Therefore, engineers gain reliable shaft speed, phase, and timing data for advanced protection and diagnostics.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Model Number | 3500/25-01-01-00 |
| Product Type | Enhanced Keyphasor Module |
| Series Compatibility | Bently Nevada 3500 Machinery Protection System |
| Number of Channels | 2 independent Keyphasor channels |
| Input Sensor Type | Keyphasor proximity probes |
| Input Signal Type | Proximitor-based pulse signals |
| Frequency Range | 1 to 20,000 RPM (configurable) |
| Speed Accuracy | ±0.01% of reading |
| Phase Reference | Once-per-revolution or multiple-event |
| Signal Conditioning | Integrated filtering and pulse shaping |
| Output Interface | 3500 rack backplane |
| Energy Storage | Internal capacitors for signal stability |
| Electrical Isolation | Channel-to-channel isolation |
| Rack Slot Requirement | One full-height 3500 monitor slot |
| Power Consumption | Supplied by 3500 rack power supply |
| Status Indicators | Front-panel OK and channel LEDs |
| Configuration | Via 3500 Configuration Software |
| Connector Type | Backplane connector |
| Housing Material | Industrial-grade metal enclosure |
| Dimensions (Approx.) | 241 mm × 24 mm × 99 mm |
| Weight (Approx.) | 0.45 kg |
| Operating Temperature | −30 °C to +65 °C |
| Storage Temperature | −40 °C to +85 °C |
| Relative Humidity | Up to 95%, non-condensing |
| EMC Compliance | CE compliant |
| Typical Applications | Speed measurement, phase reference, overspeed logic |
| Manufacturing Origin | United States |
FAQ
A1: Yes, this module is 100% brand-new, original, and factory-sealed from Bently Nevada.Q2: Do you have this Enhanced Keyphasor Module in stock?
A2: Yes, we keep available inventory for immediate shipment.
Q3: What is the typical delivery timeframe?
A3: Delivery usually takes 3 days to 2 weeks, depending on order quantity.
Q4: Which shipping carriers do you use?
A4: We commonly ship using DHL, FedEx, and other trusted international couriers.
Q5: How many Keyphasor probes can this module support?
A5: The 3500/25-01-01-00 supports two independent Keyphasor probe inputs.
Q6: Do you support returns if quality issues occur?
A6: Yes, we support returns within 30 days for confirmed quality-related issues.
