Overview
Moreover, it integrates seamlessly with the 3300 XL monitoring system to provide precise vibration and position signals.
In addition, the probe’s 8 mm design allows installation in compact machinery spaces without compromising measurement accuracy.
Therefore, it is widely used by reliability engineers to detect imbalance, misalignment, and early-stage bearing wear.
Specification
| Parameter | Description |
|---|---|
| Model | 330101-00-08-20-02-05 |
| Probe Type | NSv 8 mm proximity transducer |
| Measurement Function | Shaft displacement and vibration detection |
| Probe Diameter | 8 mm |
| Measurement Range | 0 – 500 µm peak-to-peak (typical) |
| Sensitivity | 200 mV/mil |
| Frequency Response | 0.5 Hz – 10 kHz |
| Phase Capability | Supports phase reference for relative shaft motion analysis |
| Connector Type | Standard 3300 XL module-compatible |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Environmental Rating | Industrial-grade, vibration and shock resistant |
| Mounting | Compatible with 3300 XL rack and system layout |
| Calibration | Front-panel adjustable via 3300 XL system |
| Protection Features | EMI shielding, overvoltage and short-circuit protection |
| Typical Applications | Turbines, compressors, pumps, motors, and generators |
| Standards Compliance | Meets Bently Nevada industrial vibration monitoring standards |
FAQ
Yes, it fully integrates with all 3300 XL modules for displacement and vibration monitoring.
Q2: What is the measurement range of the probe?
The typical range is 0–500 µm peak-to-peak, suitable for most industrial rotating machinery.
Q3: Can it operate in harsh industrial environments?
Yes, it is designed to withstand vibration, shock, and temperature extremes.
Q4: What is the probe’s sensitivity?
It delivers a sensitivity of 200 mV/mil for precise shaft displacement measurement.
