Overview
Moreover, it acts as an essential signal conditioning component within the 3300 XL proximity transducer system, ensuring precise data acquisition.
In addition, this Proximitor Sensor converts raw probe signals directly into stable voltage outputs, enabling real-time monitoring of shaft vibration, axial position, and rotor movement.
As a result, engineers can confidently track machine health and detect anomalies under demanding operating conditions.
Furthermore, the 3300 XL platform offers long-term stability, repeatable performance, and compliance with industry machinery protection standards.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Model Number | 330100-90-00 |
| Product Series | 3300 XL |
| Product Type | Proximitor Sensor / Proximity Transducer |
| Compatible Probe Size | 8 mm proximity probes |
| Measurement Principle | Eddy current, non-contact displacement sensing |
| Typical Measurement Range | Up to 2 mm (80 mils), system dependent |
| System Configuration | Probe, extension cable, and Proximitor Sensor |
| Output Signal Range | -24 Vdc to -17 Vdc proportional output |
| Nominal Sensitivity | 7.87 V/mm (200 mV/mil) |
| Linearity | Within specified system accuracy limits |
| Frequency Response | Suitable for vibration and position measurements |
| Power Supply Requirement | -24 Vdc nominal |
| Current Consumption | Low current, continuous-duty design |
| Operating Temperature Range | -35 °C to +85 °C |
| Environmental Rating | Industrial control cabinet environments |
| Mounting Options | DIN rail or panel mounting |
| Electrical Interface | Screw terminal connections |
| Compliance Standards | API 670 compliant when system-qualified |
| System Compatibility | Bently Nevada 3300 XL machinery protection system |
| Typical Service Life | Designed for long-term continuous operation |
FAQ
A1: It converts proximity probe signals directly into stable voltage outputs for precise vibration and position monitoring.
Q2: Which probes are compatible with this sensor?
A2: The sensor is designed for use with Bently Nevada 3300 XL 8 mm proximity probes.
Q3: Can this sensor operate continuously in vibration monitoring applications?
A3: Yes, it is engineered for continuous-duty operation in demanding rotating machinery environments.
Q4: Is the 330100-90-00 compliant with API 670 requirements?
A4: When installed in a qualified 3300 XL system, it fully meets applicable API 670 standards.
Q5: Does the sensor require field calibration after installation?
A5: No, factory calibration ensures plug-and-play performance with approved probes and extension cables.
Q6: Which industries commonly use this Proximitor Sensor?
A6: It is widely applied in power generation, oil and gas, petrochemical, and heavy industrial facilities.
