Overview
Moreover, it acts as a key signal conditioning component within the proven 3300 XL proximity transducer system, ensuring seamless integration.
In addition, this Proximitor Sensor converts raw probe signals directly into stable voltage outputs for protection and condition monitoring systems.
As a result, it enables engineers to monitor shaft vibration, axial position, and rotor movement with exceptional precision under demanding conditions.
Furthermore, engineers trust the 3300 XL platform for its long-term stability, repeatable performance, and strict compliance with industry machinery standards.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada (Baker Hughes) |
| Model Number | 330100-50-05 |
| Product Series | 3300 XL |
| Product Type | Proximitor Sensor / Proximity Transducer |
| Compatible Probe Size | 8 mm proximity probes |
| Measurement Principle | Eddy current, non-contact displacement sensing |
| Typical Measurement Range | Up to 2 mm (80 mils), system dependent |
| System Configuration | Probe, extension cable, and Proximitor Sensor |
| Output Signal Range | -24 Vdc to -17 Vdc proportional output |
| Nominal Sensitivity | 7.87 V/mm (200 mV/mil) |
| Linearity | Within specified system accuracy limits |
| Frequency Response | Suitable for vibration and position measurements |
| Power Supply Requirement | -24 Vdc nominal |
| Current Consumption | Low current, continuous-duty design |
| Operating Temperature Range | -35 °C to +85 °C |
| Environmental Rating | Industrial control cabinet environments |
| Mounting Options | DIN rail or panel mounting |
| Electrical Interface | Screw terminal connections |
| Compliance Standards | API 670 compliant when system-qualified |
| System Compatibility | Bently Nevada 3300 and compatible monitoring systems |
| Typical Service Life | Designed for long-term continuous operation |
FAQ
A1: The sensor converts proximity probe signals directly into stable voltage outputs, thereby enabling precise machinery vibration and position monitoring.
Q2: Which probes are compatible with the 330100-50-05 sensor?
A2: This sensor is specifically designed to work with Bently Nevada 3300 XL 8 mm proximity probes, ensuring seamless system integration.
Q3: Can this sensor be used for continuous vibration monitoring?
A3: Yes, it operates continuously under demanding conditions, making it ideal for real-time monitoring of critical rotating machinery.
Q4: Is the 330100-50-05 compliant with API 670 requirements?
A4: When engineers install it within a qualified 3300 XL system, it fully meets all applicable API 670 standards.
Q5: Does the Proximitor Sensor require field calibration after installation?
A5: No, factory calibration guarantees plug-and-play performance, and it works directly with approved probes and extension cables.
Q6: What industries commonly use this Proximitor Sensor?
A6: In addition, this sensor is widely applied in power generation, oil and gas, petrochemical, and heavy industrial facilities.
