Overview
In addition, the 3300 XL 11 mm system replaces legacy 7200-series 11 mm and 14 mm transducers. Therefore, when upgrading, engineers must replace all components, and monitoring systems, such as the 3500 series, require updated configuration software. Moreover, the system maintains full interchangeability between components, allowing consistent and repeatable performance across all installations.
For instance, this system is ideal for axial (thrust) position, ramp differential expansion measurements, rod position monitoring on reciprocating compressors, tachometer measurements, zero speed sensing, and Keyphasor phase reference applications. Consequently, engineers gain reliable and accurate data, which supports high-performance machinery monitoring and effective maintenance decisions.
Specification
| Parameter | Specification |
|---|---|
| Model | 330707-00-62-10-01-00 |
| Probe Type | 3300 XL 11 mm Proximity Probe |
| System Components | 1 probe, 1 extension cable, 1 Proximitor sensor |
| Output Signal | 3.94 V/mm (100 mV/mil) |
| Proximitor Sensor Input | Accepts 3300 XL 11 mm probe and extension cable |
| Power Supply | -17.5 Vdc to -26 Vdc without barriers, max 12 mA |
| Supply Sensitivity | <2 mV change per volt change in input voltage |
| Output Resistance | 50 Ω |
| Target Material | AISI 4140 steel (≥31 mm / 1.2 in diameter) |
| Probe Gap | 2.5 mm (100 mils) |
| Operating Temperature | 0°C to +45°C (+32°F to +113°F) |
| Maximum Altitude | 2000 meters |
| Typical Applications | Axial position, ramp differential expansion, rod position, Keyphasor |
| Agency Approval Option | Not required |
| Connector and Cable-Type Option | Miniature coaxial ClickLoc connector with connector protector, standard cable |
| Total Length Option | 1.0 meter (3.3 feet) |
FAQ
A: It accurately measures both static displacement and dynamic vibration.
Q: Can it replace older 7200-series 11 mm or 14 mm systems?
A: Yes, all components must be replaced, and compatible monitoring systems updated.
Q: What is the probe gap for standard operation?
A: The recommended probe gap is 2.5 mm (100 mils).
Q: What power supply is required for the system?
A: It operates on -17.5 Vdc to -26 Vdc, with a maximum of 12 mA.
Q: What applications are best suited for this transducer?
A: Axial position, rod drop, ramp expansion, Keyphasor signals, and tachometer measurements.
