Overview
Moreover, its dual-channel architecture allows simultaneous monitoring of two independent signals, enhancing predictive maintenance programs.
As a result, engineers can detect imbalance, misalignment, or bearing degradation early, reducing the risk of unexpected downtime.
In addition, the module’s 11mm proximity transducer design provides high sensitivity and broad measurement range, making it suitable for turbines, compressors, pumps, and large industrial motors.
Specification
| Parameter | Description |
|---|---|
| Model | 3300/16-15-01-01-00-00-01 |
| Module Type | Dual Vibration Monitor / NSv Proximity Transducer Interface |
| Probe Gap | 11 mm for high-precision proximity sensors |
| Input Channels | 2 independent channels for dual-transducer monitoring |
| Sensor Compatibility | Compatible with 3300 XL NSv 11mm proximity probes |
| Measurement Range | 0–10 mm shaft displacement typical |
| Vibration Frequency Range | 0.5 Hz to 10 kHz for broad machinery coverage |
| Phase Measurement | ±180° phase detection between channels |
| Signal Output | 4–20 mA displacement, optional voltage outputs, phase reference signal |
| Accuracy | ±1% full scale under industrial conditions |
| Resolution | 0.001 mm (1 µm) per channel |
| Response Time | <100 ms for rapid detection of vibration events |
| Signal Processing | RMS, peak, and phase calculation in real time |
| Mounting | Standard 3300 XL system rack slots |
| Environmental Ratings | Industrial-grade, vibration and temperature resistant |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Power Supply | Supplied via 3300 XL rack backplane (24 VDC nominal) |
| Protection Features | Short-circuit, overvoltage, and EMI protection included |
| Calibration | Front-panel adjustable potentiometers |
| Weight | Approx. 1.2 kg per module |
| Dimensions | Standard 3300 XL rack module size (HxWxD) |
| System Role | Early detection of imbalance, misalignment, and bearing wear |
| Typical Applications | Turbines, compressors, pumps, motors, and generators |
| Compliance / Standards | IEEE 1451, industrial vibration monitoring standards |
FAQ
It monitors shaft vibration and displacement using dual 11mm NSv proximity transducers.
Q2: How many channels does the module support?
This module supports two independent transducer channels simultaneously.
Q3: Is it compatible with existing 3300 XL systems?
Yes, it integrates seamlessly with standard 3300 XL NSv racks.
Q4: Can it be installed without stopping other system modules?
Moreover, it allows retrofitting while maintaining continuous monitoring of existing modules.
Q5: What maintenance is required for optimal performance?
Routine inspection and calibration are recommended, while the robust design reduces frequent servicing.
