Overview
Moreover, its XY/GAP monitoring capability enables simultaneous measurement of radial vibration and shaft position using proximity transducers.
Therefore, reliability teams can identify shaft movement, rotor instability, and clearance changes before equipment damage occurs.
In addition, the NSv proximity transducer design supports installations with limited space while maintaining high measurement accuracy.
Specification
| Parameter | Description |
|---|---|
| Model | 3300/16-15-01-03-00-00-02 |
| Module Type | Dual Vibration XY/GAP Monitor |
| Sensor Type | NSv proximity transducers |
| Probe Size | 11 mm proximity probe system |
| Input Channels | 2 channels configurable for XY vibration or GAP measurement |
| Measurement Functions | Radial shaft vibration, shaft position (gap), and relative displacement |
| Measurement Range | Typical 0–10 mm shaft displacement |
| Frequency Response | 0.5 Hz to 10 kHz |
| Phase Capability | Supports phase reference and relative shaft movement analysis |
| Signal Output | 4–20 mA current signals, with optional voltage outputs |
| Accuracy | ±1% full scale under normal operating conditions |
| Resolution | Up to 1 µm peak-to-peak displacement resolution |
| Response Time | Less than 100 ms for dynamic vibration events |
| Signal Processing | Real-time RMS, peak, and gap calculation |
| Mounting | Standard 3300 XL system rack slot |
| Power Supply | Powered through 3300 XL rack backplane |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Environmental Rating | Industrial-grade, vibration-resistant construction |
| Protection Features | Overvoltage, short-circuit, and EMI protection |
| Calibration Method | Front-panel adjustable controls |
| Typical Applications | Turbines, compressors, pumps, motors, and generators |
| System Role | Continuous monitoring of shaft vibration and clearance |
| Standards Compliance | Industrial vibration monitoring standards |
| Displacement Option | 0–500 µm peak-to-peak measurement range |
| Transducer Input Option | Compatible with 3300 8 mm, 3300 XL 8 mm, and 7200 5 mm or 8 mm proximitor sensors |
| Proximitor Sensitivity | 200 mV per mil |
| Alarm Relay Option | Quad relay output, epoxy-sealed configuration |
| Trip Multiply Option | Selectable trip multiply values: 0, 2×, or 3× |
FAQ
It measures radial shaft vibration in two directions and shaft position or clearance simultaneously.Q2: Which sensors work with this module?
This module supports Bently Nevada XL NSv 11mm proximity transducers.
Q3: Is this module compatible with existing 3300 XL racks?
Yes, it installs directly into standard 3300 XL system racks.
Q4: Can it support predictive maintenance programs?
Moreover, it provides early detection of shaft movement and vibration anomalies.
Q5: What maintenance does the module require?
Routine inspection and calibration ensure optimal performance, while the design minimizes service effort.
