Overview
Moreover, its dual-channel design allows operators to monitor two vibration signals simultaneously, enhancing predictive maintenance strategies.
Therefore, engineers can detect early signs of imbalance, misalignment, and bearing wear, preventing costly unplanned downtime.
In addition, the 11mm probe system ensures high sensitivity and extended measurement range, making it suitable for turbines, compressors, pumps, and large motors.
Specification
| Parameter | Description |
|---|---|
| Model | 3300/16-14-01-03-00-00-00 |
| Module Type | Dual Vibration Monitor / Proximity Transducer Interface |
| Probe Gap | 11 mm standard for high-precision proximity sensors |
| Input Channels | 2 independent channels for dual transducer monitoring |
| Sensor Compatibility | Compatible with 3300 XL 11mm proximity probes |
| Measurement Range | 0–10 mm shaft displacement typical for rotating machinery |
| Vibration Frequency Range | 0.5 Hz to 10 kHz for broad machinery coverage |
| Phase Measurement | ±180° phase detection between channels |
| Signal Output | 4–20 mA displacement, optional voltage, phase reference outputs |
| Accuracy | ±1% full scale typical under industrial conditions |
| Resolution | 0.001 mm (1 µm) per channel |
| Response Time | <100 ms for rapid vibration detection |
| Signal Processing | RMS, peak, and phase calculation performed in real-time |
| Mounting | Installs in standard 3300 XL system racks |
| Environmental Ratings | Industrial-grade, vibration and temperature resistant |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Power Supply | Provided via 3300 XL rack backplane (24 VDC nominal) |
| Protection Features | Overvoltage, short-circuit, and EMI protection included |
| Calibration | Adjustable via front-panel potentiometers |
| Weight | Approx. 1.2 kg per module |
| Dimensions | Standard 3300 XL rack module size (HxWxD) |
| System Role | Early detection of imbalance, misalignment, and bearing wear |
| Typical Applications | Turbines, compressors, pumps, motors, and generators |
| Compliance / Standards | IEEE 1451 and industrial vibration monitoring standards |
FAQ
It monitors shaft vibration and displacement using dual 11mm proximity transducers.
Q2: How many channels does the module support?
This module supports two independent transducer channels for simultaneous measurement.
Q3: Is it compatible with all 3300 XL systems?
Yes, it integrates seamlessly with standard 3300 XL system racks.
Q4: Can it be installed without interrupting existing monitoring systems?
Moreover, it allows retrofitting while maintaining continuous monitoring of other modules.
Q5: What maintenance does this module require?
Routine inspection and calibration are recommended, while the robust design reduces service frequency.
