Overview
Specification
| Specification | Details |
|---|---|
| Model Number | 176449-01 |
| Module Type | Proximitor Monitor |
| System Compatibility | Bently Nevada 3500 Series Machinery Protection System |
| Input Channels | 1 proximitor transducer input |
| Output Signals | Analog (4–20 mA), Digital alarms |
| Proximitor Excitation | 10 VDC nominal |
| Signal Bandwidth | DC to 10 kHz |
| Accuracy | ±0.25% of full-scale typical |
| Alarm Functions | Sensor fault, high vibration, displacement limits |
| Isolation | Channel-to-channel: ≥ 500 V; Channel-to-system: ≥ 1500 V |
| Power Supply | 24 VDC nominal, ±10% |
| Power Consumption | ≤ 4 W typical |
| Operating Temperature | -20°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Humidity | 5%–95% RH, non-condensing |
| Vibration / Shock Resistance | IEC 60068-2-6 / IEC 60068-2-27 compliant |
| Mounting | Standard 3500 Series rack-mountable |
| Dimensions | Approx. 35 x 120 x 180 mm (H x W x D) |
| Weight | ~0.45 kg |
| Certifications | CE, UL, and Bently Nevada quality compliance |
FAQ
A1: It supports proximitor transducers for shaft displacement and vibration monitoring.
Q2: Is this module compatible with all 3500 Series racks?
A2: Yes, the 176449-01 integrates seamlessly with standard 3500 Series racks.
Q3: What alarm functions are available on this module?
A3: It provides sensor fault detection, high vibration, and displacement limit alarms.
Q4: Can this module operate in extreme industrial environments?
A4: Yes, it is designed for rugged operation under temperature, vibration, and humidity stress.
Q5: How does this module support predictive maintenance?
A5: By providing accurate real-time proximitor data, it enables early fault detection and maintenance planning.
Q6: What is the typical power consumption of the 176449-01?
A6: The module typically consumes 4 W under normal operating conditions.
