Overview
communicate, and to mount power supplies necessary to distribute power to each module.
Specification
| Parameter | Specification |
|---|---|
| Part Number | 3500/05-01-01-05-00-01 |
| Product Type | System Rack for 3500 Monitor Modules |
| Compatible Modules | Bently Nevada 3500 Series Modules |
| Rack Size | 19-inch Full-Size Rack (14 module slots) |
| Mini-Rack Option | 12-inch Mini-Rack (7 module slots) |
| Mounting Formats | Panel Mount, Rack Mount, Bulkhead Mount |
| Mounting Notes | Mini-Rack not available in Bulkhead Mount format |
| Power Supply Placement | Far-left rack positions required |
| Dimensions | Full-size 19″ EIA, Mini-rack 12″ |
| Material | Steel, powder-coated |
| Cooling | Ventilated for temperature control |
| Environmental Rating | Industrial operating conditions |
| Certifications | FCC, EMC 2014/30/EU, LV 2014/35/EU, RoHS 2011/65/EU |
| Marine Certification | ABS, DNV GL |
| Access Orientation | Front or rear, depending on mounting format |
| European Compliance Option | CE Marked |
| Reserved Option | None |
FAQ
A1: The full-size rack accommodates up to 14 3500 monitoring modules.
Q2: What mounting formats are available for this system rack?
A2: Panel mount, rack mount, and bulkhead mount formats are available (mini-rack excludes bulkhead mount).
Q3: Are the racks certified for industrial and marine environments?
A3: Yes, they comply with FCC, EMC, LV, RoHS, and are ABS/DNV GL certified.
Q4: Where should power supplies be installed in the rack?
A4: Power supplies and interface modules must occupy the far-left positions for proper system operation.
