Overview
Moreover, it belongs to the proven Bently Nevada 3300 XL series, ensuring high stability in harsh industrial environments.
Therefore, operators gain reliable real-time data for rotating machinery protection and condition monitoring.
Designed for integration with the Bently Nevada 3500 series, the 145193-01 supports critical machinery diagnostics across power generation and process industries.
In addition, its robust construction maintains signal accuracy under temperature changes and mechanical stress.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Model Number | 145193-01 |
| Product Type | Proximitor Sensor |
| Series / Platform | 3300 XL Proximity Transducer System |
| Measurement Principle | Eddy current, non-contact displacement sensing |
| Measured Parameters | Shaft vibration, shaft position, displacement |
| Compatible Probe Size | 8 mm proximity probe |
| System Components | Proximitor sensor, proximity probe, extension cable |
| Nominal Output Signal | 200 mV/mil (7.87 mV/µm) |
| Output Signal Type | Analog voltage, negative-going |
| Linear Measurement Range | 2.0 mm (80 mils) typical |
| Usable Frequency Response | 0 to 10 kHz |
| Target Material | Ferromagnetic steel shafts |
| Calibration Standard | AISI 4140 steel target |
| Supply Voltage | −24 VDC nominal (−18 VDC to −30 VDC operating range) |
| Current Consumption | Approximately 12 mA |
| Output Load Resistance | ≥ 10 kΩ |
| Electrical Isolation | Internally isolated signal conditioning |
| Connector Type | Two-piece terminal block |
| Mounting Method | Panel-mounted or DIN rail via bracket |
| Housing Material | Aluminum alloy with protective coating |
| Environmental Protection | Industrial-grade, oil and vibration resistant |
| Operating Temperature | −40 °C to +85 °C |
| Storage Temperature | −51 °C to +100 °C |
| Relative Humidity | Up to 95%, non-condensing |
| Shock Resistance | 100 g peak, 11 ms duration |
| Vibration Resistance | 10 g RMS, 10–2000 Hz |
| Dimensions (Approx.) | 102 mm × 25 mm × 76 mm |
| Weight (Approx.) | 0.25 kg |
| Compliance | CE, RoHS |
| Typical System Integration | Bently Nevada 3500 Series monitors |
| Country of Origin | United States |
FAQ
A1: Yes, the 145193-01 is 100% brand new, factory-sealed, and original Bently Nevada equipment.
Q2: Do you keep this proximity sensor in stock?
A2: Yes, we maintain stock for the 145193-01, allowing fast order processing.
Q3: How fast can you ship this product?
A3: Shipping typically occurs within 3 days to 2 weeks, depending on order quantity.
Q4: Which logistics providers do you usually use?
A4: We commonly ship via DHL and other reliable international express couriers.
Q5: What is the return policy if quality issues occur?
A5: We support returns within 30 days if any quality issue arises.
Q6: What systems work with the 145193-01 proximity sensor?
A6: The 145193-01 works with 3300 XL Proximitor® drivers and integrates into Bently Nevada 3500 systems.
