Overview
Designed for the 3500 Machinery Protection System, it combines proximity and seismic measurements within a single monitoring module.
Moreover, the module supports early fault detection, therefore helping plants protect assets and avoid costly unplanned shutdowns.
Specification
| Parameter | Specification |
|---|---|
| Brand | Bently Nevada (Baker Hughes) |
| Model / Part Number | 140734-02 |
| Module Type | 3500/42M Proximitor / Seismic Monitor |
| System Platform | Bently Nevada 3500 Machinery Protection System |
| Input Channels | 4 channels, configurable |
| Supported Sensors | Proximitor probes, seismic velocity sensors, accelerometers |
| Measurement Types | Shaft displacement, vibration, seismic motion |
| Signal Processing | Real-time dynamic vibration analysis |
| Alarm Functions | Alert and danger setpoints per channel |
| Protection Role | Machinery protection and condition monitoring |
| Rack Compatibility | Standard 3500 system rack |
| Power Supply | Supplied directly from the 3500 rack backplane |
| Diagnostics | Continuous self-monitoring of module and sensor status |
| Operating Temperature | –30 °C to +65 °C |
| Environmental Design | Suitable for continuous industrial operation |
| Compliance | Designed to meet applicable machinery protection standards |
FAQ
A1: It measures proximity, vibration, and seismic signals to monitor and protect rotating machinery.
Q2: How many channels does this monitor provide?
A2: The module provides four configurable monitoring channels.
Q3: Which sensors are compatible with this module?
A3: It supports Proximitor probes, seismic velocity sensors, and compatible accelerometers.
Q4: Can this module be installed in existing 3500 racks?
A4: Yes, it installs directly into standard Bently Nevada 3500 system racks.
Q5: How does this monitor improve machinery reliability?
A5: It detects abnormal vibration and displacement early, therefore reducing the risk of unexpected machinery failures.
