Overview
Specification
| Specification | Details |
|---|---|
| Model | 138700-01 |
| Manufacturer | Bently Nevada |
| Series | 3500 Machinery Protection System |
| Module Type | Shaft Absolute I/O Module with External Terminations |
| Monitoring Channels | 2 independent shaft channels |
| Signal Type | Absolute position outputs, analog and digital options |
| Input Compatibility | Shaft-mounted proximity or position sensors |
| Output Signals | ±10 V analog, optional digital communications |
| Rack Slot Requirement | Standard 3500 system rack, single-width |
| Front Panel Indicators | Channel status LEDs, fault indicators |
| Power Supply | Supplied via 3500 system backplane |
| Energy Storage | Internal capacitors stabilize transient signals |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity Tolerance | 5% to 95% RH, non-condensing |
| Vibration Immunity | Designed for high-vibration industrial environments |
| Mounting Method | Slide-in rack installation with secure locking mechanism |
| Diagnostic Features | Continuous self-check, fault detection, and alarm signaling |
| Typical Applications | Turbines, compressors, generators, and other rotating machinery |
| Compliance Standards | Meets Bently Nevada 3500 system quality and safety specifications |
FAQ
A1: Yes, all modules are fully new and factory-sealed for guaranteed authenticity.
Q2: What is the typical lead time for delivery?
A2: Standard shipping ranges from 3 days to 2 weeks depending on order size and destination.
Q3: Which logistics providers are used?
A3: We commonly ship via DHL, FedEx, or other reliable international carriers.
Q4: Can I return the module if it has a quality issue?
A4: Yes, we offer a 30-day return policy for any quality-related concerns.
Q5: What type of sensors are compatible with this module?
A5: The module supports shaft-mounted proximity sensors and absolute position transducers.
Q6: Can it be integrated into existing 3500 racks?
A6: Yes, the module is fully compatible with standard 3500 system racks and backplanes.
