Overview
Specification
| Parameter | Specification |
|---|---|
| Power Consumption | 4.5 Watts typical |
| Input Voltage | 24 Vdc nominal, range 18–30 Vdc |
| Input Channels | 4 Proximitor channels, 2 seismic channels |
| Sensor Excitation | 4 mA per Proximitor channel, 24 Vdc for seismic sensors |
| Output Channels | Buffered ±5 Vdc outputs for Proximitor signals |
| Input Impedance | > 22 kΩ for Proximitor inputs |
| Frequency Response | 0.1 Hz to 20 kHz for seismic channels |
| Signal Conditioning | Low-pass, high-pass, and gain selectable via front panel |
| Front Panel Indicators | OK (green), Channel Fault (red) LEDs |
| Operating Temperature | 0°C to +65°C (32°F to +149°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Relative Humidity | Up to 95%, non-condensing |
| Main Module Dimensions | 241.3 mm x 24.4 mm x 103.1 mm |
| Main Module Weight | 0.48 kg (1.06 lbs) |
| Rack Space Requirement | 1 full-height 3500 rear slot |
| Compliance | FCC Part 15, EMC EN 61000-6-2/-6-4, RoHS, ABS, DNV GL, CSA/NRTL/C |
FAQ
A1: Yes, it is fully new and factory original.Q2: How fast can it be shipped?
A2: We ship within 3 days to 2 weeks depending on order size.
Q3: Which shipping options are available?
A3: Common options include DHL, UPS, and FedEx.
Q4: What if there is a quality issue?
A4: We support returns within 30 days if a quality problem occurs.
Q5: Which sensors are compatible?
A5: Compatible with Proximitor and seismic transducers requiring external excitation.
