Overview
Moreover, this module connects field transducers directly to compatible monitor cards with stable and repeatable signal performance.
Engineers select 126615-01 modules to maintain consistent data quality across proximity and seismic measurement points.
Therefore, machinery protection strategies gain stronger diagnostic confidence during continuous operation.
Specification
| Category | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Model | 126615-01 |
| Series | 3500 Machinery Protection System |
| Module Type | Proximitor Seismic Monitor I/O Module |
| Primary Function | Signal termination and routing for proximitor and seismic inputs |
| Compatible Monitors | 3500 Proximitor and Seismic Monitor modules |
| Supported Channels | Multiple vibration input channels |
| Sensor Types Supported | Proximity probes, seismic velocity sensors, accelerometers |
| Termination Style | Rack-mounted rear I/O termination |
| Electrical Interface | Direct connection to 3500 monitor backplane |
| Isolation | Electrical isolation supporting low-noise signal transmission |
| Front Connectors | None, rear I/O wiring only |
| Module Height | Half-height 3500 I/O module |
| Dimensions (H × W × D) | Approx. 241 mm × 25 mm × 99 mm |
| Weight | Approx. 0.35 kg |
| Power Source | Supplied through 3500 rack backplane |
| Power Consumption | Low power, monitor-dependent |
| Energy Storage | No onboard batteries or capacitors |
| Cooling Method | Passive cooling via rack airflow |
| Operating Temperature | -30°C to +65°C |
| Storage Temperature | -40°C to +85°C |
| Operating Humidity | Up to 95% non-condensing |
| Installation Location | Rear I/O slot within 3500 rack |
| Typical Applications | Turbines, compressors, pumps, motors, rotating machinery |
FAQ
A1: Yes, the 126615-01 ships as brand new, factory original, and fully sealed.
Q2: Do you have the 126615-01 in stock?
A2: Yes, we keep the 126615-01 in stock for immediate availability.
Q3: How fast can you ship this module after ordering?
A3: Shipping typically requires 3 days to 2 weeks, depending on order quantity.
Q4: Which logistics carriers do you use for delivery?
A4: We commonly ship using DHL and other trusted international logistics providers.
Q5: Which sensors work with the 126615-01 I/O module?
A5: The 126615-01 supports proximity probes, seismic sensors, and accelerometers.
Q6: Do you accept returns if quality issues occur?
A6: Yes, we support returns within 30 days if any verified quality issue occurs.
