Overview
Specification
| Parameter | Specification |
|---|---|
| Model | 10024/H/I |
| Module Type | Communication Module |
| Function | Enables communication between FSC modules and external systems |
| Communication Interfaces | FSC bus interface, optional external network connections |
| Safety Compliance | SIL 2 / SIL 3 capable |
| Operating Voltage | 24 V DC nominal, 20–30 V DC operational range |
| Operating Temperature | -40°C to +70°C (-40°F to +158°F) |
| Storage Temperature | -50°C to +85°C (-58°F to +185°F) |
| Mounting | Standard FSC rack slot |
| Diagnostics | LED indicators for module status and communication |
| Response Time | Deterministic, <5 ms typical |
| Electromagnetic Compatibility | EN 61326-1 compliant |
| Shock & Vibration Resistance | 15 g shock; vibration 5–150 Hz compliant |
| Certifications | CE, SIL, FM approved |
FAQ
Q1: What is the main purpose of the 10024/H/I module?
A1: It enables reliable communication between FSC modules and external systems for safe operations.
Q2: Is this module suitable for SIL-certified applications?
A2: Yes, it is SIL 2 / SIL 3 capable, ensuring compliance with safety standards.
Q3: What communication interfaces are supported?
A3: The module supports FSC bus interfaces and optional external network connections.
Q4: Does it provide diagnostics for troubleshooting?
A4: Yes, LED indicators display module and communication status in real time.
Q5: What is the operating voltage range?
A5: The module operates from 20–30 V DC, nominal 24 V DC.
Q6: What environmental conditions can it operate under?
A6: It functions safely from -40°C to +70°C with 5–95% non-condensing humidity.
