Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | CC-TFE021-3 (Base Model: CC-TFE021) |
| Brand | Honeywell |
| Origin | USA |
| Product Type | Analog Output Termination Assembly / IOTA Baseplate |
| System Compatibility | Honeywell Experion PKS C300 / Series C I/O |
| Configuration | Non-Redundant Analog Output Interface |
| Weight | Approx. 0.5 – 1.0 kg |
| Dimensions | Approx. 14.8 cm x 7.6 cm x 26.9 cm |
| Operating Temp | -20 deg C to +70 deg C |
| Storage Temperature | -40 deg C to +85 deg C |
| Relative Humidity | 5% to 95% non-condensing |
| Power Consumption | 24 VDC nominal supply interface |
| Mounting Type | Vertical Series C IOTA mounting format |
| Coating Type | Conformal Coated protection layer |
| Isolation | Channel-to-channel and channel-to-ground isolation |
| Field Interface | Analog Output field wiring termination |
DCS Signal Isolation and Loop Interface Characteristics
The Honeywell CC-TFE021-3 operates as a physical termination interface for Series C analog output channels. It organizes field wiring connections and maintains electrical separation between individual signal paths. In addition, the conformal coating protects the assembly surface from moisture, sulfurous gases, and airborne industrial contaminants.
The assembly supports Honeywell process control architectures where analog output devices require direct connection to field actuators, valves, and positioners. Furthermore, the channel-to-channel isolation design reduces interference between independent analog output loops.
For Honeywell Experion PKS applications, the termination assembly supports standard process instrumentation interfaces associated with analog control loops. The hardware design allows connection management without changing the active field wiring arrangement.
Frequently Asked Questions
Q: Does the CC-TFE021-3 support redundant analog output configuration?
A: No. The CC-TFE021-3 is specified for non-redundant analog output termination applications within the Honeywell Series C I/O architecture.
Q: Can the CC-TFE021-3 protect connected field wiring in corrosive environments?
A: Yes. The conformal coating provides protection against humidity, sulfurous gases, and chemical vapor exposure.
Q: Does the CC-TFE021-3 provide signal isolation between channels?
A: Yes. The assembly provides channel-to-channel and channel-to-ground isolation for connected analog output circuits.
Field Installation Guidelines
- Install the CC-TFE021-3 on the designated Series C IOTA mounting position according to Honeywell cabinet installation procedures.
- Verify that field wiring terminals match the assigned analog output channel configuration before connection.
- Maintain proper cable routing separation between analog signal wiring and high-current power conductors.
- Connect cable shields according to the control system grounding practice to reduce electromagnetic interference.
- Confirm that the conformal coated surface remains free from mechanical damage during installation.
- Inspect terminal connections for correct tightening and secure field conductor placement before system startup.
