Overview
Moreover, it provides deterministic solid-state outputs designed specifically for demanding industrial safety and shutdown applications.
Built with conformal coating, this module ensures stable performance in harsh environments with moisture, dust, and chemical exposure.
Therefore, safety engineers trust it to maintain operational integrity in high-risk industrial processes.
Specification
| Specification | Details |
|---|---|
| Model Number | FC-SDO-0824 |
| Product Series | Honeywell FSC Safety Manager |
| Module Type | Safety Digital Output Module |
| Coating Type | Conformal coated (CC) |
| Version | CCV1.2 |
| Number of Output Channels | 8 |
| Output Type | 24 Vdc solid-state source |
| Short-Circuit Protection | Yes |
| Maximum Output Current | 550 mA per channel |
| Current Derating | 350 mA at 70°C |
| Maximum Lamp Load | 120 mA (2.9 W) |
| Maximum Load Capacitance | 1 µF |
| Voltage Drop | < 2.0 Vdc at 500 mA |
| Off-State Current | < 0.1 mA |
| Watchdog Input Current | 8 mA |
| Internal Power Supply | 24 Vdc, 25 mA |
| External Power Supply | 24 Vdc, 70 mA (no load) |
| Logic Power Requirement | 5 Vdc, 25 mA |
| Space Requirement | 4 TE, 3 HE (4 HP, 3U) |
| Approvals | CE, TÜV, UL, CSA, FM |
| Key Coding | Holes A9, C9 / Large pins A9, C9 |
FAQ
Q1: What is the main purpose of the Honeywell FC-SDO-0824 module?
A1: The FC-SDO-0824 provides safety-rated digital outputs for controlling critical field devices in Safety Manager systems.
Q2: How many output channels does the FC-SDO-0824 support?
A2: This module offers eight independent 24 Vdc solid-state output channels for reliable safety control.
Q3: What is the advantage of the conformal coating on this module?
A3: Conformal coating improves resistance to moisture, dust, and corrosion in harsh industrial environments.
Q4: Does the FC-SDO-0824 include short-circuit protection?
A4: Yes, each output channel features built-in short-circuit protection to enhance system safety and reliability.
Q5: What safety certifications does this module carry?
A5: The FC-SDO-0824 is approved by CE, TÜV, UL, CSA, and FM for safety-critical applications.
Q6: Which applications commonly use the FC-SDO-0824 module?
A6: Engineers typically use it in emergency shutdown systems, fire and gas protection, and safety interlock control.
