Overview
Specification
| Parameter | Specification / Details |
|---|---|
| Model Number | 900A16-0103 |
| Series | FSC (Field System Controller) |
| Module Type | High Level Analog Input Module |
| Number of Channels | 16 analog inputs |
| Input Type | Voltage and current (configurable per channel) |
| Input Range | 0–10 V, 4–20 mA |
| Resolution | 16-bit ADC |
| Accuracy | ±0.1% of full scale |
| Response Time | <10 ms per channel |
| Isolation | Channel-to-channel and channel-to-backplane isolation |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 5% to 95% non-condensing |
| Vibration Resistance | 5–500 Hz, 0.5 g RMS |
| Shock Resistance | 15 g, 11 ms half-sine pulse |
| Mounting | FSC backplane compatible; optional DIN rail |
| Dimensions | 120 mm x 100 mm x 40 mm (approx.) |
| Weight | 1.0 kg (approx.) |
| Compliance / Certification | CE, UL, CSA, RoHS |
| Maintenance | Hot-swappable with built-in diagnostics for preventive maintenance |
FAQ
Q1: How many analog input channels does this module provide?
A1: The 900A16-0103 provides 16 high-level analog input channels for flexible process monitoring.
Q2: What types of analog signals can the module measure?
A2: It supports both voltage (0–10 V) and current (4–20 mA) signals configurable per channel.
Q3: Can this module operate in harsh industrial environments?
A3: Yes, it is designed to withstand vibration, shock, temperature extremes, and non-condensing humidity.
Q4: Is the module compatible with FSC controllers?
A4: Absolutely, it integrates seamlessly with FSC backplane systems for reliable control.
Q5: Can modules be replaced without shutting down the system?
A5: Yes, the 900A16-0103 is hot-swappable, allowing maintenance without operational downtime.
Q6: Does the module support diagnostics for preventive maintenance?
A6: Yes, built-in diagnostics continuously monitor channel status and simplify maintenance procedures.
