Overview
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 8C-TAOXB1 51307137-175 |
| Brand | Honeywell |
| Product Type | Analog Output Module |
| Series | Experion PKS Series 8 I/O |
| Origin | USA |
| Weight | 0.34 kg |
| Dimensions | 29.3 x 12 x 6.5 cm |
| Operating Temp | 0 to 60 deg C |
| Storage Temperature | -40 to 85 deg C |
| Power Consumption | 190 mA module current rating at 24 VDC supply |
| Output Channels | 16 |
| Voltage Rating | 24 VDC |
| Load Resistance | 50-800 ohm |
| Resolution | +/- 0.05% of Full Scale |
| Directly Settable Output Current Range | 2.9 mA to 21.1 mA |
| Maximum Open Circuit Voltage | 22 V |
| Diagnostics | Extensive self diagnostics |
| Redundancy Support | Optional redundancy configuration |
| Tariff Code | 8537101190 |
| Shipment Location | Xiamen, China |
Process Signal Loop Characteristics
The Honeywell 8C-TAOXB1 51307137-175 operates as a Series 8 Analog Output module for generating controlled analog current signals. It supports 16 output channels with configurable current output capability from 2.9 mA to 21.1 mA.
The module provides channel-level signal processing for process control applications. In addition, the output circuit supports load resistance between 50 ohm and 800 ohm while maintaining specified output resolution.
The module uses Honeywell Experion PKS I/O architecture and supports optional redundancy configurations. Therefore, system designers can integrate additional availability functions when required by the control system configuration.
Channel Isolation and DCS Signal Interface
Honeywell Series 8 I/O modules are designed for process control environments requiring controlled analog signal transmission. The 8C-TAOXB1 51307137-175 supports standard analog output practices used in DCS architectures.
The module operates with current loop output behavior similar to 4-20 mA process instrumentation interfaces. Furthermore, Honeywell process I/O designs support channel-to-channel signal separation concepts to reduce interference between field circuits.
The output electronics provide diagnostic functions that monitor module operation and assist system maintenance activities. These diagnostics help identify abnormal module states during operation.
Frequently Asked Questions
Q: How many analog output channels does the Honeywell 8C-TAOXB1 51307137-175 provide?
A: The module provides 16 analog output channels for process signal generation.
Q: What current output range can the 8C-TAOXB1 51307137-175 directly set?
A: The module supports a directly settable output current range from 2.9 mA to 21.1 mA.
Q: Does the 8C-TAOXB1 51307137-175 support redundant operation?
A: Yes. The module supports optional redundancy configuration within compatible Honeywell Series 8 I/O system architectures.
Field Installation Guidelines
Install the Honeywell 8C-TAOXB1 51307137-175 module in the designated Series 8 I/O carrier position according to the system hardware configuration.
Verify that the 24 VDC supply wiring meets the required polarity and power distribution standards before energizing the module. Connect field analog output wiring using appropriate shielded instrumentation cables when signal noise reduction is required.
Terminate cable shields according to the site grounding practice. Keep analog signal wiring separated from high-current power cables and switching circuits to reduce electromagnetic interference.
Before operation, confirm channel assignments, output scaling parameters, and controller configuration within the Experion PKS engineering environment.
