Overview
Specifically, it converts resistance temperature detector signals into stable, actionable data for continuous machinery condition assessment.
Moreover, the module integrates seamlessly with legacy Bently Nevada 3300 racks that operators still rely on across critical industrial assets.
Therefore, maintenance teams obtain dependable temperature insight while preserving existing protection architectures and minimizing system changes.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Model Numbers | 79532-01, 82369-01 |
| Product Type | 4-Wire RTD Input Module |
| Series / System | 3300 Machinery Protection System |
| Primary Function | RTD temperature signal acquisition and conditioning |
| Input Signal Type | 4-wire Resistance Temperature Detector (RTD) |
| Number of Input Channels | 6 independent RTD channels |
| Supported RTD Types | Platinum, Nickel, Copper RTDs (system configurable) |
| Wiring Method | Four-wire configuration |
| Lead Resistance Compensation | Yes, inherent through four-wire wiring method |
| Excitation Method | Balanced constant current excitation |
| Signal Conditioning | Linearized and filtered for machinery protection monitoring |
| System Compatibility | Bently Nevada 3300/35 RTD Monitor |
| Power Supply | Supplied via 3300 system rack backplane |
| Electrical Isolation | Internal noise reduction and signal stability design |
| Alarm Processing | Performed by associated 3300 monitoring modules |
| Calibration Method | Configured and calibrated through system monitor |
| Installation Method | Plug-in, rack-mounted module |
| Mechanical Construction | Rugged industrial terminal module housing |
| Operating Environment | Continuous industrial machinery protection applications |
| Vibration Resistance | Suitable for rotating equipment environments |
| Operating Temperature Range | Dependent on RTD type and monitor configuration |
| Typical Pt100 Measurement Range | Up to approximately 500°C |
| Typical Nickel RTD Range | Up to approximately 150°C |
| Typical Copper RTD Range | Up to approximately 100°C |
| Maintenance Requirement | Minimal; periodic inspection recommended |
| Application Industries | Power generation, oil and gas, petrochemical, heavy industry |
FAQ
A1: It measures RTD temperature signals and supplies accurate data to the 3300 machinery protection system.Q2: Why does this module use a four-wire RTD configuration?
A2: The four-wire method reduces lead resistance errors, improving temperature measurement accuracy and stability.
Q3: Is this module compatible with all Bently Nevada systems?
A3: It is specifically designed for use within the Bently Nevada 3300 Machinery Protection System.
Q4: Which industries commonly use this RTD input module?
A4: Power generation, oil and gas, petrochemical, and heavy industrial facilities commonly deploy this module.
Q5: Can this module support long-term continuous operation?
A5: Yes, it is engineered for continuous monitoring in demanding industrial environments.
