Overview
Moreover, this 3500 Series module continuously measures cylinder pressure, providing critical real-time data for machinery protection.
It integrates seamlessly with the 3500 Series protection system, enabling immediate detection of abnormal pressure events.
Consequently, operators can reduce mechanical failures, extend equipment lifespan, and support predictive maintenance programs.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Series | 3500 Machinery Protection System |
| Model Number | 3500/77M 140734-07 |
| Module Type | Cylinder Pressure Monitor |
| Monitoring Function | Real-time cylinder pressure measurement |
| Number of Channels | 8 (configurable) |
| Input Sensor | Pressure transducers compatible with 3500 system |
| Output | Alarm and trip signals for system integration |
| Measurement Range | Configurable based on sensor type |
| Alarm Types | Alert and danger setpoints |
| System Integration | Compatible with 3500 rack-mounted modules |
| Communication Interface | 3500 backplane connection |
| Power Supply | Rack-supplied DC power |
| Energy Storage | None |
| Diagnostics | Continuous channel validation and sensor monitoring |
| Operating Environment | Industrial reciprocating machinery |
| Mounting Style | Rack-mounted module (3500 system) |
| Dimensions (H × W × D) | Approx. 241 mm × 99 mm × 241 mm |
| Weight | Approx. 1.5 kg |
| Construction | Industrial-grade electronics with EMI shielding |
FAQ
Yes, the 3500/77M 140734-07 is factory-new and original.
Q2: Is this module in stock?
Yes, inventory is available for immediate orders.
Q3: What is the typical delivery timeframe?
Delivery generally takes 3 days to 2 weeks depending on order size.
Q4: Which logistics carriers are used for shipping?
We typically ship via DHL or other reliable carriers.
Q5: Can I return the product if a quality issue occurs?
Yes, returns are supported within 30 days for any verified quality issues.
