Overview
This 3500 Series Position Monitor Module delivers accurate analog signal processing and integrates seamlessly into existing machinery protection systems.
Moreover, the module supports continuous monitoring in harsh industrial environments, ensuring reliable early fault detection.Engineers use the 3500/45 176449-04 to detect axial movement, shaft misalignment, and other position-related anomalies quickly.
Consequently, plants benefit from improved machinery safety, extended asset life, and reduced unplanned downtime.
Specification
| Parameter | Specification |
|---|---|
| Model | 3500/45 176449-04 |
| Manufacturer | Bently Nevada |
| Series | 3500 Machinery Protection Series |
| Module Type | Position Monitor Module |
| Primary Function | Shaft and machinery position signal monitoring and conditioning |
| Supported Sensors | Linear displacement transducers, shaft position sensors, proximity probes, LVDTs |
| Input Signal Type | Analog voltage signals representing absolute or relative position |
| Input Channels | 2–4 independent channels depending on configuration |
| Channel Architecture | Fully isolated multi-channel design to prevent cross-talk |
| Signal Conditioning | Low-noise analog filtering, amplification, and stabilization |
| Output Signals | Analog voltage outputs compatible with 3500 Series monitoring modules |
| Backplane Interface | Direct connection to 3500 Series system backplane |
| Rack Compatibility | Standard 3500 Series rack, single-slot width |
| Physical Dimensions (H × W × D) | 241 mm × 24 mm × 99 mm (approximate) |
| Weight | ~0.3 kg |
| Power Supply | Supplied via 3500 Series backplane, 5V DC typical operating voltage |
| Energy Storage | Low stored-energy internal design ensuring safety |
| Operating Environment | Industrial machinery protection and monitoring cabinets |
| Typical Applications | Turbines, compressors, generators, pumps, motors |
