Overview
This enhanced Keyphasor module accurately converts probe inputs into speed, phase, and timing references for monitoring systems.
Engineers rely on 3500/25 149369-01 to support vibration analysis, transient events, and advanced diagnostics across rotating assets.
Designed for the Bently Nevada 3500 Series, 3500/25 149369-01 installs directly into a standard 3500 rack slot.
The module continuously conditions Keyphasor signals while maintaining deterministic timing for protection and condition monitoring.
Specification
| Category | Specification |
|---|---|
| Product model | 3500/25 149369-01 |
| Manufacturer | Bently Nevada |
| Product category | Enhanced Keyphasor Module |
| System series | Bently Nevada 3500 Machinery Protection System |
| Primary function | Generates precise speed, phase, and timing reference signals |
| Channel quantity | 2 independent Keyphasor input channels |
| Channel configuration | Channel A and Channel B operate independently |
| Input signal type | Proximity probe Keyphasor input |
| Supported probe types | Bently Nevada proximity probes compatible with 3500 Series |
| Input signal form | Once-per-revolution or multiple-event per revolution |
| Output signal purpose | Rotational speed, phase reference, and timing synchronization |
| Signal processing | Real-time digital conditioning and phase-stable conversion |
| Rack compatibility | Standard 3500 rack slot |
| Module placement | Rear-slot monitored module |
| Front-panel indicators | OK status LED, Channel A LED, Channel B LED |
| Power supply source | 3500 rack power supply |
| Typical power consumption | Approximately 5.8 W |
| Internal energy storage | None, no batteries or backup capacitors |
| Start-up behavior | Immediate operation after rack power stabilization |
| Synchronization capability | Fully synchronized with vibration and transient monitoring modules |
| Communication interface | Internal 3500 rack data bus |
| Configuration method | 3500 Rack Configuration Software |
| Operating temperature range | 0°C to +65°C |
| Storage temperature range | −40°C to +85°C |
| Relative humidity limit | Up to 95% non-condensing |
| Shock resistance | Designed for industrial machinery environments |
| Vibration resistance | Suitable for continuous operation in rotating equipment systems |
| Module height | Approximately 120.7 mm |
| Module width | Approximately 25.4 mm |
| Module depth | Approximately 241 mm |
| Approximate weight | 0.34 kg |
| Mounting method | Direct insertion into 3500 rack backplane |
| Typical applications | Turbines, compressors, generators, pumps, rotating machinery |
| Compliance | Designed to meet industrial machinery protection standards |
