Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 3500/15 125840-01 |
| Brand | Bently Nevada (GE) |
| Product Type | High Voltage AC Power Input Module |
| Input Voltage Range | 85 to 250 Vac rms |
| Nominal Voltage | 110 to 220 Vac |
| Input Frequency | 47 to 63 Hz |
| Associated Power Supply | 3500/15 High Voltage AC Power Supply |
| Full Rack Current Draw | 2.8 A rms (maximum) |
| Protection | Fuse opens on over-voltage condition |
| Hot-Swap Capability | Yes |
| Rack Configuration | Dual-slot redundant support |
| Power Supply Module Dimensions (H × W × D) | 120.7 × 50.8 × 251.5 mm (4.75 × 2.0 × 9.9 in) |
| Power Supply Module Weight | 1.39 kg (3.06 lb) |
| Power Input Module Dimensions (H × W × D) | 120.7 × 25.4 × 114.3 mm (4.75 × 1.0 × 4.5 in) |
| Power Input Module Weight | 0.34 kg (0.75 lb) |
| Operating Temperature | -30°C to +65°C (-22°F to +150°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Humidity | 95% non-condensing |
| Compliance | CE, CSA, ATEX/IECEx industrial safety standards |
FAQ
It supports an input voltage range of 85 to 250 Vac rms, making it suitable for high-voltage industrial systems.Q2: Can this module operate redundantly with another power input module?
Yes. Two modules can operate in parallel—one as primary and the other as backup—for continuous operation.
Q3: Is the 3500/15 125840-01 compatible with DC power supplies?
No. It is designed exclusively for high voltage AC configurations within the 3500 system.
Q4: Can the module be replaced while the rack is powered on?
Yes. It supports hot-swap functionality, allowing safe removal and replacement without interrupting system power.
Q5: What environmental conditions can it withstand?
It operates reliably between -30°C to +65°C and up to 95% humidity, ensuring performance in harsh settings.
