Overview
Moreover, this interconnect cable supports seamless integration with Bently Nevada 3300 XL proximity transducers, allowing operators to implement predictive maintenance strategies effectively. Therefore, it contributes to machinery protection for turbines, compressors, and large motors, enhancing operational safety and efficiency.
The cable’s flexibility and durable construction simplify installation and maintenance, reducing downtime and operational risk. Furthermore, it ensures accurate data transmission from proximity probes to monitoring modules, enabling precise vibration and shaft displacement measurements.
Specification
| Parameter | Specification |
|---|---|
| Model Number | 330102-00-24-10-02-00 |
| Cable Type | Interconnect Cable for 3300 XL 8 mm Proximity Transducers |
| Standard Length | 2 meters (custom lengths available upon request) |
| Conductor Material | High-purity, oxygen-free copper for low signal loss |
| Conductor Configuration | Twisted pair with foil and braid shielding for EMI/RFI protection |
| Insulation Material | PTFE (high temperature and chemical resistant) |
| Jacket Material | Flexible, abrasion-resistant fluoropolymer for harsh environments |
| Connector Type | Bently-approved Proximitor connectors (male/female) |
| Connector Rating | 5 Amps, 300 V DC |
| Operating Temperature Range | -40°C to +125°C (-40°F to +257°F) |
| Voltage Rating | 300 V DC nominal |
| Capacitance | ≤ 100 pF/ft typical between conductors |
| Shielding Effectiveness | ≥ 85 dB from 10 kHz to 100 MHz |
| Bend Radius | Minimum 10x cable diameter |
| Environmental Protection | Resistant to oil, dust, moisture, and industrial chemicals |
| Compliance | CE certified, RoHS compliant |
| Typical Applications | Connecting 3300 XL proximity probes to monitoring modules for vibration and shaft displacement measurements |
| Reliability Features | High vibration, thermal shock, and contaminant resistance for continuous operation |
| Warranty | Standard manufacturer warranty, extended service available |
FAQ
A1: This cable connects Bently Nevada 3300 XL 8 mm proximity probes to the monitoring modules, transmitting precise shaft displacement and vibration signals.
Q2: What is the maximum operating temperature for this cable?
A2: The cable operates reliably between -40°C and +125°C (-40°F to +257°F), suitable for harsh industrial environments.
Q3: Can this cable be used in environments with high electrical noise?
A3: Yes, its twisted-pair design with foil and braid shielding provides excellent EMI/RFI protection for accurate signal transmission.
Q4: Are custom cable lengths available?
A4: Yes, standard length is 2 meters, but custom lengths can be requested to fit specific machinery layouts.
Q5: How durable is this cable in industrial conditions?
A5: The cable jacket is abrasion-resistant and chemically resistant, providing high durability against oil, dust, moisture, and vibration.
Q6: Is the cable compliant with industrial safety standards?
A6: Yes, it is CE certified, RoHS compliant, and designed to meet rigorous industrial performance and safety requirements.
