Overview
Moreover, this module allows simultaneous monitoring of two independent proximity transducer signals, enabling comprehensive protection for complex machines.
Therefore, engineers detect shaft displacement, imbalance, and misalignment before failures escalate.
In addition, the module integrates seamlessly into the 3300 XL rack system, optimizing space and simplifying installation for industrial facilities.
Specification
| Category | Parameter | Description |
|---|---|---|
| General Information | Product Model | 3300/65-14-01-00-00-01-00 |
| General Information | Module Type | Dual Probe Monitor Module |
| System Platform | 3300 XL Rack Compatibility | Fully compatible with 3300 XL machinery protection racks |
| Sensor Compatibility | Supported Sensors | NSv proximity transducer systems |
| Channel Configuration | Number of Channels | 2 independent channels (Channel A and Channel B) |
| Measurement Functions | Functions Monitored | Shaft displacement, radial vibration, relative movement between probes |
| Measurement Range | Full-Scale Range | 0–100 µm peak-to-peak typical (per channel) |
| Signal Processing | Velocity/Displacement Conversion | Converts displacement inputs to velocity and displacement readings |
| Alarm Configuration | Alarm Options | Independent alert and danger alarms for each channel |
| Alarm Relay Option | Relay Output | Quad relay (Velomitor style) supporting plant interlocks |
| Accuracy | Measurement Accuracy | ±1% full-scale under normal operating conditions |
| Resolution | Signal Resolution | Up to 1 µm displacement resolution |
| Response Time | Dynamic Response | Less than 100 ms to transient vibration events |
| Mounting | Rack Slot | Standard 3300 XL rack slot |
| Power Supply | Source | Powered through 3300 XL rack backplane |
| Operating Environment | Temperature | -20°C to +70°C |
| Storage Conditions | Temperature | -40°C to +85°C |
| Environmental Protection | Industrial Design | Vibration-resistant, overvoltage and EMI-protected construction |
| Typical Applications | Equipment | Turbines, compressors, pumps, generators, motors |
| System Role | Function | Continuous dual-probe monitoring for early fault detection |
| Standards Compliance | Industry Standards | Complies with industrial machinery vibration and position monitoring standards |
FAQ
Yes, therefore each channel independently monitors one NSv proximity transducer signal.
Q2: What is the maximum displacement range per channel?
Each channel supports 0–100 µm peak-to-peak displacement measurement.
Q3: How does the module integrate with existing 3300 XL systems?
It installs in a standard 3300 XL rack slot and receives power from the rack backplane.
Q4: Are configurable alarms available for both channels?
Yes, each channel provides independent alert and danger alarms with quad relay outputs.
