Overview
Specification
| Specification | Details |
|---|---|
| Model Number | 3500/60‑163179‑01 |
| Module Type | Temperature Monitor |
| System Compatibility | Bently Nevada 3500 Machinery Protection System |
| Number of Channels | Six independent temperature channels |
| Supported Sensors | Resistance Temperature Detectors (RTDs) and Thermocouples (TCs) |
| RTD Temperature Range | −200°C to +850°C typical (sensor‑dependent) |
| TC Temperature Range | −270°C to +1820°C typical (sensor‑dependent) |
| Input Impedance | ~10 MΩ per lead |
| Power Supply Voltage | 24 VDC (drawn from 3500 rack backplane) |
| Power Consumption | Nominal ~7 W |
| Alarm Setpoints | Programmable high/low thresholds with hysteresis |
| Isolation | TC isolated versions offer 250 Vdc channel‑to‑channel isolation |
| Operating Temperature Range | −40°C to +85°C |
| Storage Temperature Range | −55°C to +125°C |
| Mounting | Standard 3500 series rack insertion |
| Dimensions (Approx.) | 241.3 mm × 24.4 mm × 241.8 mm |
| Weight | ~0.91 kg |
| Certifications | CE, UL 508, RoHS (varies by revision) |
FAQ
It supports six independent temperature channels for simultaneous monitoring.
Q2: What types of sensors are compatible?
It accepts both RTDs and thermocouples, accommodating various industrial temperature measurement requirements.
Q3: Can alarm thresholds be configured by users?
Yes, each channel’s high and low alarm setpoints are programmable to suit application needs.
Q4: Does this module include signal isolation?
Yes, TC isolated versions provide channel‑to‑channel isolation to reduce interference.
Q5: What rack system does it integrate with?
It integrates into the Bently Nevada 3500 series rack and shares data across modules.
Q6: What are typical operating conditions?
It operates reliably from −40°C to +85°C with a wide storage temperature range.
