Overview
Specification
| Parameter | Specification / Description |
|---|---|
| Module Type | Ethernet / RS485 Modbus I/O Module |
| Rack Compatibility | Bently Nevada 3500 Series Racks |
| Communication Protocols | Ethernet TCP/IP, Modbus RS485 |
| Data Transmitted | All rack-monitored values, digital statuses, and alarms |
| Software Compatibility | 3500 Rack Configuration Software, Data Acquisition Software |
| Module Width | Single-slot module |
| Power Supply | 24 V DC nominal, typical current 0.5–1.0 A |
| Operating Temperature | 0–65 °C |
| Storage Temperature | -40–85 °C |
| Relative Humidity | 5–95%, non-condensing |
| Mounting | 3500 Series rack mountable |
| Hot-Swap Capability | Yes, supports replacement without system shutdown |
| Data Latency | <50 ms typical for Ethernet communication |
| Status Indicators | LEDs for communication and module health |
| Agency Approvals | CSA/NRTL/C; optional CSA/ATEX for hazardous areas |
| Compliance Standards | API 670, IEC 61131, EMC EN50081-1/50082-2 |
FAQ
A1: Yes, it supports both Ethernet TCP/IP and RS485 Modbus communication simultaneously.
Q2: Is the module compatible with all 3500 Series racks?
A2: Yes, it integrates fully with Bently Nevada 3500 Series Machinery Protection System racks.
Q3: Can it integrate with process control systems?
A3: Yes, it supports integration with DCS, PLC, and SCADA platforms for plant automation.
Q4: Is the module hot-swappable?
A4: Yes, its modular design allows replacement without shutting down the system.
Q5: What are the environmental operating conditions?
A5: It operates between 0–65 °C with 5–95% non-condensing humidity and standard vibration tolerance.
Q6: Are there hazardous area approvals available?
A6: Optional CSA/ATEX approvals are available for installation in hazardous environments.
