Overview
This termination block provides robust external connection points for critical phasor signal wiring, ensuring reliable signal routing in industrial environments.
Moreover, it works with 3500/25 Enhanced Keyphasor modules and uses Euro‑style connectors to simplify external cabling.
Specification
| Category | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Product Series | 3500 Machinery Protection System |
| Model Number | 128718-01 |
| Module Type | Keyphasor External Termination Block |
| Core Function | Provides organized termination for Keyphasor signal cables outside the rack |
| Compatible Module | 3500/25 Enhanced Keyphasor Module |
| Connector Style | Euro‑style terminal blocks for easy field wiring |
| Input Channels | Supports multiple Keyphasor sensor inputs (phasor signals, speed reference) |
| Output Channels | Routed to 3500/25 Keyphasor module via pass-through wiring |
| Electrical Interface | Passive; no amplification or signal conditioning |
| Power Requirement | None; fully passive block |
| Internal Components | Mechanical terminals only; no electronics or circuitry |
| Mounting Type | External to 3500 rack, secured with screws or clips |
| Module Dimensions | Approx. 242 mm × 30 mm × 25 mm |
| Dimensions (Imperial) | Approx. 9.5 in × 1.18 in × 0.98 in |
| Module Weight | Approx. 0.06 kg (0.13 lb) |
| Environmental Ratings | Industrial machinery environments; vibration resistant |
| Wire Compatibility | Stranded or solid copper wires, compatible with Keyphasor sensors |
| Installation Notes | Provides clean cable management; allows maintenance without rack disassembly |
| Reliability Features | Ensures signal integrity under vibration, temperature variations, and field handling |
| Typical Applications | Turbines, compressors, generators, pumps using 3500/25 Enhanced Keyphasor module |
FAQ
A1: It provides external connection points for Keyphasor signal wiring to the 3500/25 module.
Q2: Does the 128718-01 require power or internal electronics?
A2: No, this termination block is a passive connection interface with no power or electronics.
Q3: Which connectors does it use?
A3: The 128718-01 uses Euro‑style external connectors for neat field wiring.
Q4: Which Keyphasor module does this support?
A4: It pairs with the 3500/25 Enhanced Keyphasor Module in the 3500 system.
Q5: Is the 128718-01 suitable for harsh industrial environments?
A5: Yes, it is designed for reliable signal termination in industrial settings.
Q6: Is this block brand new and original?
A6: Yes, the 128718-01 is factory original, new, and supplied with genuine manufacturer quality.
