Overview
Engineers appreciate the 10513-02 for its compact dimensions and standardized interface, which seamlessly integrate with existing 3500 Series racks. Therefore, the module promotes flexible system expansion while simplifying routine inspection procedures. Furthermore, its durable materials resist corrosion and mechanical wear, allowing operators to maintain long-term reliability even in demanding industrial environments.
Specification
| Parameter | Specification | Notes / Additional Info |
|---|---|---|
| Model Number | 10513-02 | Bently Nevada OEM |
| Module Type | Clamp Drawer | Terminal connection interface |
| Compatible Series | 3500 Machinery Protection | Integrates with 3500 Series modules |
| Dimensions | 203 mm (L) x 50 mm (W) x 100 mm (H) | Approximate, depends on rack configuration |
| Weight | 0.45 kg | Lightweight for ease of handling |
| Number of Terminal Slots | 16–32 depending on module configuration | Supports various module types |
| Material | Stainless steel and industrial-grade plastic | Ensures durability and corrosion resistance |
| Electrical Rating | 5A max per terminal | Suitable for industrial signal levels |
| Mounting Type | Rack-mounted | Fits standard 3500 Series racks |
| Operating Temperature | -20°C to +70°C | Industrial operating range |
| Environmental Protection | IP20 | Standard industrial protection |
| Integration | Works with 3500 Series main and I/O modules | Seamless system connectivity |
FAQ
A1: Yes, the 10513-02 Clamp Drawer is engineered specifically for 3500 Series racks and modules, ensuring seamless integration and reliable electrical connections.
Q2: What is the recommended environment for installing the 10513-02?
A2: Install the 10513-02 in dry, industrial environments, avoiding excessive vibration or moisture to maintain optimal performance.
Q3: How does the 10513-02 facilitate module replacement?
A3: The clamp drawer allows quick insertion and removal of modules, minimizing downtime during maintenance or system upgrades.
Q4: What materials ensure the durability of the 10513-02?
A4: Constructed with corrosion-resistant metals and durable plastics, the 10513-02 withstands industrial wear and maintains reliable performance over time.
Q5: Can the 10513-02 support system expansion?
A5: Yes, its standardized interface allows additional modules to be added easily, supporting flexible system expansion for growing operations.
