Overview
The Honeywell 10313/1/1 (10313/1/1 FSC Termination Module) provides termination interfaces for hardware connections within Honeywell FSC safety control systems. Its documented product classification identifies it as an FSC Termination Module. The available specifications define its model, physical dimensions, and weight; electrical ratings, signal assignments, and connector pinouts require confirmation from the manufacturer’s documentation.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 10313/1/1 |
| Brand | Honeywell |
| Product Type | FSC Termination Module |
| System | Honeywell FSC |
| Origin | USA |
| Weight | 0.34 kg |
| Dimensions | 245 x 87 x 68 mm |
| Module Function | FSC termination |
FSC Termination Interface Characteristics
The 10313/1/1 belongs to the Honeywell FSC (Fail-Safe Controller) hardware family and is identified as a termination module. Termination hardware provides physical connection points for associated control-system wiring. However, the available information does not establish this module’s exact signal assignments, internal circuitry, or compatibility with specific processor and I/O module revisions.
The previously supplied description mentions 5 VDC watchdog signal distribution, but the provided technical specifications do not independently confirm that function. Verify the circuit assignment and interface requirements against the applicable FSC hardware documentation before installation or replacement.
Frequently Asked Questions (FAQ)
Q: What is the function of the Honeywell 10313/1/1?
A: It is classified as an FSC Termination Module for the Honeywell FSC safety control system. Detailed terminal functions require the applicable wiring documentation.
Q: What are the physical dimensions and weight?
A: The estimated shipping dimensions are 245 x 87 x 68 mm, and the listed weight is 0.34 kg. The shipping dimensions should not be treated as verified module dimensions.
Q: Can the 10313/1/1 be replaced with another FSC termination module?
A: Compatibility cannot be determined from the model number alone. Check terminal assignments, electrical interfaces, mechanical fit, and the applicable FSC hardware revision before selecting a replacement.
Field Installation Guidelines
- Confirm the complete model number and inspect the module for physical damage before installation.
- Verify the mounting arrangement and connector orientation against the FSC hardware documentation.
- Identify each field conductor using the applicable terminal assignment and wiring diagram.
- Keep signal wiring separated from power and high-interference conductors where practical.
- Apply grounding and shielding practices specified in the manufacturer’s installation instructions.
- Do not apply power or connect watchdog signals based solely on assumptions about the module’s function.
- Verify system compatibility and perform the prescribed continuity and functional checks before returning the control system to service.
