Overview
Specification
| Parameter | Specification |
|---|---|
| Model | 10300/1/1 |
| Module Type | Converter Module |
| Function | Converts input signals to FSC-compatible formats |
| Input Signal Type | Analog or digital signals from field or system devices |
| Output Signal Type | FSC bus-compatible output signals |
| Safety Compliance | SIL 2 / SIL 3 capable |
| Operating Voltage | 24 V DC nominal, 20–30 V DC operational range |
| Operating Temperature | -40°C to +70°C (-40°F to +158°F) |
| Storage Temperature | -50°C to +85°C (-58°F to +185°F) |
| Mounting | FSC standard rack slot |
| Diagnostics | LED indicators for module status and signal conversion |
| Response Time | ≤ 50 ms typical |
| Electromagnetic Compatibility | EN 61326-1 compliant |
| Shock & Vibration Resistance | 15 g shock; vibration 5–150 Hz compliant |
| Certifications | CE, SIL, FM approved |
FAQ
Q1: What is the primary function of the 10300/1/1 module?
A1: It converts analog or digital signals into FSC bus-compatible formats for seamless system integration.
Q2: Is the module suitable for safety-critical applications?
A2: Yes, it is SIL 2 / SIL 3 capable, ensuring compliance with international safety standards.
Q3: What types of input signals does it support?
A3: The module supports both analog and digital signals from field devices or system modules.
Q4: How quickly does it convert signals?
A4: Signal conversion typically occurs within 50 ms under normal operating conditions.
Q5: Does the module provide diagnostics for troubleshooting?
A5: Yes, LED indicators display real-time status of the module and signal conversion.
Q6: What is the operating temperature range for the module?
A6: It operates reliably between -40°C and +70°C, suitable for demanding industrial environments.
