Overview
Configured for catalytic sensor signal processing in Honeywell System 57 gas detection networks, the Honeywell 05701-A-0284 (05701-A-0284 Catalytic Sensor Drive Card) provides direct physical/electrical execution for single-channel gas detector monitoring and alarm processing.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | 05701-A-0284 |
| Brand | Honeywell Analytics |
| Origin | USA |
| Operating Temp | -10 deg C to +50 deg C |
| Power Consumption | < 3.5 W (sensor dependent) |
| System Compatibility | Honeywell System 57 |
| Module Type | Catalytic Sensor Drive Card |
| Channel Capacity | 1 channel |
| Input Signal | Catalytic bead bridge sensor input; compatible sensor configurations vary by wiring setup |
| Alarm Functions | Three configurable alarm levels: A1, A2, A3 |
| Display Interface | Backlit LCD with digital gas concentration display and status indication |
| Output Interface | Configurable alarm and fault relay outputs; 4-20 mA concentration signal output |
| Mounting Method | Plug-in card installation within System 57 rack assembly |
Process Instrumentation Loop Interface
The Honeywell 05701-A-0284 interfaces with gas detection field devices through dedicated sensor signal conditioning circuits. The module processes catalytic sensor bridge signals, converts detector responses into calibrated gas concentration values, and provides alarm status information through the System 57 control architecture.
The card supports industrial instrumentation practices including 4-20 mA loop protocol interfaces where applicable within the connected System 57 configuration. Channel-to-channel isolation requirements depend on the installed rack configuration and connected field wiring arrangement.
Frequently Asked Questions
Q: What sensor type is supported by the 05701-A-0284?
A: The module is designed for catalytic sensor drive applications within the Honeywell System 57 platform. The connected detector type and wiring configuration determine the applicable sensor characteristics.
Q: Does the 05701-A-0284 provide independent alarm processing?
A: Yes. The card processes a single sensor channel and provides configurable alarm levels, fault monitoring, and relay status outputs through the System 57 architecture.
Q: Can the module operate outside the System 57 rack environment?
A: No. The 05701-A-0284 is designed as a plug-in control card for Honeywell System 57 rack assemblies and requires the associated backplane and power connections.
Field Installation Guidelines
- Install the module only within a compatible Honeywell System 57 rack assembly.
- Verify rack power availability and backplane connections before inserting the card.
- Maintain separation between sensor signal wiring and high-voltage power cables to reduce electrical interference.
- Connect cable shields according to site grounding practices and avoid multiple-point shield grounding loops.
- Confirm catalytic sensor wiring polarity and termination before commissioning.
- Perform sensor calibration and alarm verification after installation according to the system maintenance procedure.
- Inspect the card seating position and connector engagement before applying system power.
