Overview
The Honeywell MC-PLAM02 51304362-150, also cataloged as the MC-PLAM02 Low Level Analog Input Multiplexer Processor, operates as a dedicated hardware component for multiplexing and scanning low-level analog signals within Honeywell process control systems. The module supports 32 inputs and processes multiplexed signals at an input scan rate of 32 samples per second. It also provides configurable synchronization with 50 Hz or 60 Hz line frequencies.
Hardware Specifications
| Parameter | Specification |
|---|---|
| Model | MC-PLAM02 51304362-150 |
| Base Model | MC-PLAM02 |
| Product Type | Low Level Analog Input Multiplexer Processors |
| Brand | Honeywell |
| Product Parameters | Processor Low Level Analog Mux |
| Input Capacity | 32 inputs |
| Input Scan Rate | 32 samples per second |
| Crosstalk, DC to 60 Hz | 120 dB |
| Input Impedance | 2 Mohm minimum at 100 mV |
| Line Frequency Synchronization | Configurable to 50 Hz or 60 Hz |
| Software Accuracy | +/- 0.1 deg C typical, +/- 0.5 deg C maximum at 23.5 +/- 2 deg C |
| Tariff Code | 8537101190 |
| Origin | USA |
| Weight | 0.6 kg |
| Dimensions | 3 x 31.8 x 28 cm estimated shipping size |
Low Level Analog Signal Processing and Channel Isolation
The MC-PLAM02 processes multiple low-level analog input signals through a multiplexing architecture. Its 2 Mohm minimum input impedance at 100 mV reduces loading on connected low-level signal sources. In addition, the specified 120 dB crosstalk performance from DC to 60 Hz supports separation between multiplexed signal channels.
The configurable 50 Hz or 60 Hz line-frequency synchronization allows the scanning process to align with the local power-frequency environment. Consequently, the module can support measurement systems where line-frequency interference affects low-level analog signal acquisition.
For process instrumentation applications, low-level analog signals may originate from field circuits requiring controlled routing and shielding practices. Therefore, installation should maintain separation between low-level measurement wiring and higher-energy circuits. The supplied specifications do not identify direct support for 4-20 mA HART communication or FOUNDATION Fieldbus connectivity.
Frequently Asked Questions
Q: How many analog inputs does the Honeywell MC-PLAM02 51304362-150 support?
A: The MC-PLAM02 51304362-150 supports 32 inputs for low-level analog signal multiplexing.
Q: What is the specified input scan rate?
A: The module scans inputs at 32 samples per second according to the provided technical data.
Q: Can the MC-PLAM02 synchronize with different AC line frequencies?
A: Yes. The line-frequency synchronization is configurable for 50 Hz or 60 Hz operation.
Field Installation Guidelines
Verify the module part number and installation location before inserting the MC-PLAM02 51304362-150 into the designated Honeywell hardware assembly.
Route low-level analog signal wiring separately from high-current power conductors, motor cables, and switching circuits. This practice helps limit externally induced electrical noise.
Use shielded signal cables when the field installation requires protection against electromagnetic interference. Terminate cable shields according to the applicable Honeywell system grounding arrangement.
Confirm the configured 50 Hz or 60 Hz synchronization setting before commissioning. In addition, verify input wiring continuity and signal-source compatibility before enabling normal process operation.
Do not apply unspecified power or signal levels to module terminals. Follow the applicable Honeywell hardware documentation for rack installation, terminal assignments, grounding, and replacement procedures.
