Overview
MU-PLAM02 51304362-100 provides precise low-level analog signal acquisition for Honeywell industrial control and DCS systems.
This module belongs to the Honeywell UCN architecture, so it ensures stable integration with distributed process control networks.
Moreover, MU-PLAM02 51304362-100 functions as an analog input multiplexer processor, which improves signal handling efficiency.
It maintains accurate low-level signal processing, while it supports continuous monitoring in complex industrial environments.
Key Features and Functional Benefits
MU-PLAM02 51304362-100 supports multi-channel analog input multiplexing, so it enables efficient signal scanning and acquisition.
Additionally, the module processes low-level analog signals, which improves measurement accuracy in sensitive industrial applications.
It uses advanced signal conditioning technology, therefore it reduces noise interference and enhances data stability.
Furthermore, the compact processor design simplifies system integration, while it reduces cabinet space requirements.
Engineers benefit from high-speed channel scanning, which improves system responsiveness and control efficiency.
Specification
| Parameter | Detailed Specification |
|---|---|
| Model Number | MU-PLAM02 51304362-100 |
| Manufacturer | Honeywell |
| Product Type | Low Level Analog Input Multiplexer Processor Module |
| Series | Honeywell UCN / DCS Series |
| Function | Analog input multiplexing and signal processing |
| Input Channels | Multi-channel analog input scanning capability |
| Input Signal Type | Low-level analog signals (mV and mA range) |
| Signal Range | 0–20 mA / millivolt-level input compatibility |
| Multiplexing Speed | High-speed channel scanning for real-time acquisition |
| Resolution | High-resolution analog-to-digital conversion |
| Accuracy | High precision low-level signal measurement |
| Signal Conditioning | Integrated filtering and amplification circuits |
| Isolation Type | Channel-to-system electrical isolation |
| Isolation Voltage | Up to 500 V AC protection rating |
| Power Supply | 24 V DC system backplane supply |
| Power Consumption | Approx. 6–10 W depending on load |
| Interface Type | Backplane communication interface |
| Connector Type | Industrial edge connector for secure mounting |
| Dimensions (W×H×D) | Approx. 220 × 150 × 50 mm compact structure |
| Weight | Approx. 1.0–1.5 kg for stable installation |
| Operating Temperature | 0°C to 60°C industrial environment range |
| Storage Temperature | -40°C to 85°C safe storage conditions |
| Humidity Range | 5% to 95% non-condensing conditions |
| Mounting Method | Rack-mounted installation in Honeywell chassis |
| Protection Features | Signal noise suppression and fault detection |
FAQ
Q1: Is this product brand new and original?
Yes, MU-PLAM02 51304362-100 comes as brand new original equipment with guaranteed authenticity.
Q2: Do you have stock available?
We keep MU-PLAM02 51304362-100 in stock, so we can process orders quickly.
Q3: How fast can you ship the product?
We ship MU-PLAM02 51304362-100 within 3 days to 2 weeks, depending on order quantity.
Q4: Which logistics services do you use?
We commonly use DHL, so delivery remains fast, safe, and fully trackable.
Q5: What should I do if there is a quality issue?
We support returns for MU-PLAM02 51304362-100 within 30 days if any quality issue occurs.
Q6: What is the main function of this module?
MU-PLAM02 51304362-100 performs low-level analog input multiplexing and high-precision signal processing for Honeywell systems.
