Overview
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell |
| Product Series | FSC (Fail Safe Controller) |
| Model Number | 900R12R-0200 |
| Product Type | 12‑Slot I/O Rack with redundant power support |
| Function | Provides mechanical and electrical platform for FSC I/O modules |
| Number of Slots | 12 I/O module slots for digital, analog, or specialty modules |
| Backplane Type | FSC I/O backplane with redundant power capability |
| Redundant Power Support | Yes — supports dual‑input redundant power for enhanced uptime |
| Compatible Modules | All standard FSC Series I/O modules (digital, analog, specialty) |
| Mounting Method | DIN rail or surface mounting with screws (rack or control cabinet) |
| Backplane Connector | Standard FSC slot bus connectors for power and signal distribution |
| Operating Temperature Range | 0°C to 60°C (32°F to 140°F) typical industrial range |
| Storage Temperature Range | –40°C to +85°C (–40°F to 185°F) |
| Relative Humidity | 10%–95% non‑condensing environmental tolerance |
| Dimensions (H × W × D) | 137 mm × 683.3 mm × 151.7 mm (5.4″ × 26.9″ × 6.0″) |
| Weight | Approximately 5252 g (11.57 lb) |
| Power Supply | 24 VDC input via backplane; redundant supply capability supported |
| Power Redundancy | Supports redundant power modules to maintain uptime upon power fault |
| Rack Material | Industrial metal enclosure designed for harsh environments |
| Vibration Resistance | Designed for industrial vibration tolerance |
| EMI / RFI Immunity | Engineered for high electrical noise immunity |
| Slot Identification | Clearly labeled slots for easier module installation |
| Diagnostics | System integration enables module presence and status monitoring |
| Compliance | Suitable for FSC safety control system requirements |
| Typical Enclosure | Installed inside industrial control cabinets or racks |
| Lifecycle Support | Honeywell long‑term support and spare parts availability |
FAQ
Q1: What types of FSC modules are compatible with the 900R12R-0200 I/O Rack?
A1: The 900R12R-0200 rack supports all standard Honeywell FSC Series I/O modules, including digital input/output, analog input/output, and specialty modules.
Q2: Does the 900R12R-0200 support redundant power configurations?
A2: Yes, the rack includes a backplane designed for dual power supply redundancy, ensuring continuous operation during a power fault.
Q3: What is the recommended installation environment for this I/O rack?
A3: The rack is suitable for industrial control cabinets, with operating temperatures between 0°C and 60°C and relative humidity of 10%–95% non-condensing.
Q4: How many modules can be installed in this rack?
A4: This model provides 12 slots, allowing flexible configuration for mixed digital, analog, or specialty modules.
Q5: Can the 900R12R-0200 be mounted outside a control cabinet?
A5: While possible, installation outside a cabinet is not recommended due to exposure to dust, moisture, or vibration. Proper enclosures ensure optimal performance.
Q6: How does the rack improve system maintenance and reliability?
A6: The integrated backplane distributes power and communication signals consistently, while clear slot labeling and redundancy support simplify installation, diagnostics, and maintenance.
