Overview
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell |
| Product Series | FSC (Fail Safe Controller) |
| Model Number | 900A01-0202 |
| Module Type | Digital Output Module |
| Order Reference | 900A01-0202 |
| Number of Output Channels | 8 independent digital outputs |
| Output Type | Solid-state / relay-compatible |
| Voltage Rating | 24 VDC nominal (system-dependent) |
| Output Current Rating | 0–500 mA per channel |
| Response Time | <10 ms typical |
| Isolation | Channel-to-system galvanic isolation |
| Fault Detection | Short-circuit and open-circuit detection per channel |
| Diagnostics | Per-channel status and module health reporting |
| Status Indicators | LED indicators for channel operation and faults |
| Backplane Interface | FSC I/O backplane |
| System Compatibility | Honeywell FSC safety controllers |
| Installation Method | Plug-in, rack-mounted module |
| Operating Temperature Range | –20°C to +70°C |
| Storage Temperature Range | –40°C to +85°C |
| Vibration Resistance | Industrial-grade vibration tolerance |
| EMI / RFI Immunity | Designed for high-noise environments |
| Power Supply Requirements | Supplied through FSC backplane |
| Power Consumption | Optimized for continuous operation |
| Compliance Standards | FSC system safety and control requirements |
| Typical Applications | Valves, solenoids, relays, actuators, and safety interlocks |
| Environment | Industrial automation and safety-critical systems |
| Lifecycle Support | Honeywell documentation, spares, and long-term support |
FAQ
A1: What type of devices can the Honeywell 900A01-0202 control?
Q1: The module can control 24 VDC field devices such as valves, actuators, and relays.
A2: Is this module compatible with FSC controllers?
Q2: Yes, it integrates seamlessly with Honeywell FSC safety control systems.
A3: Does the module provide fault diagnostics?
Q3: Yes, it supports per-channel diagnostics for open-circuit or short-circuit conditions.
A4: What is the maximum current per output channel?
Q4: Each channel supports up to 500 mA continuous output safely.
A5: Can it operate in high-noise industrial environments?
Q5: Yes, it is designed with EMI/RFI immunity and robust electrical protection.
A6: How is the module installed in the system?
Q6: The module is a plug-in, rack-mounted unit that connects directly to the FSC backplane.
