Overview
Specification
| Parameter | Specification / Details |
|---|---|
| Model Number | 900B08-0202 |
| Series | FSC (Field System Controller) |
| Module Type | Analog Output Module |
| Number of Outputs | 8 analog outputs |
| Output Type | 4–20 mA, voltage configurable |
| Resolution | 16-bit digital-to-analog conversion |
| Accuracy | ±0.1% full scale |
| Response Time | 1 ms typical |
| Power Supply | 24 VDC nominal, 3 W typical |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 5% to 95% non-condensing |
| Vibration Resistance | 5–500 Hz, 0.5 g RMS |
| Shock Resistance | 15 g, 11 ms half-sine pulse |
| Mounting | FSC backplane compatible; optional DIN rail |
| Dimensions | 120 mm x 100 mm x 40 mm (approx.) |
| Weight | 0.9 kg (approx.) |
| Compliance / Certification | CE, UL, CSA, RoHS |
| Maintenance | Hot-swappable; built-in diagnostics support preventive maintenance |
FAQ
Q1: How many analog output channels does this module provide?
A1: The 900B08-0202 provides 8 analog output channels for flexible process control.
Q2: What type of outputs does the module support?
A2: It supports 4–20 mA analog outputs, which can also be configured for voltage output.
Q3: Is the module suitable for harsh industrial environments?
A3: Yes, it withstands vibration, shock, and temperature variations for reliable operation.
Q4: Can the module be integrated with existing FSC controllers?
A4: Absolutely, it integrates seamlessly with FSC controllers and backplane systems.
Q5: How accurate are the analog outputs?
A5: Outputs have ±0.1% full-scale accuracy with 16-bit resolution for precise control.
Q6: Does the module support preventive maintenance or diagnostics?
A6: Yes, built-in diagnostics continuously monitor output status and simplify preventive maintenance.
