Overview
Specification
| Parameter | Specification |
|---|---|
| Brand | Honeywell |
| Model Number | 51454833‑100 |
| Product Type | UEA Termination Assembly |
| Function | Provides termination and interface points for discrete field signals |
| Compatible Systems | Honeywell Experion PKS, TPS, PlantScape / Local Control Network (LCN) architectures |
| Signal Type Supported | Discrete Digital Inputs and Outputs |
| Termination Interfaces | Pluggable screw terminals and high‑density connectors |
| Mounting Type | Panel‑mounted or DIN‑rail compatible assembly |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Humidity Range | 5% to 95% relative humidity, non‑condensing |
| Weight | Approximately 0.6 kg (1.32 lbs) |
| Electrical Connectivity | Standard discrete I/O wiring interfaces with field controllers |
| Environmental Performance | Designed for industrial field environments with resistance to EMI/RFI interference |
| System Redundancy Compatibility | Supports redundant DCS configurations when paired with appropriate controllers |
| Labeling & Documentation | Clearly marked terminal identification for easier wiring and troubleshooting |
| Lifecycle Status | Active and supported under Honeywell Experion lifecycle programs |
| Certifications | Complies with industrial control standards for field termination assemblies |
FAQ
Q1: What is the primary function of the Honeywell 51454833-100 assembly?
A1: It provides reliable termination for analog and digital signals in Experion LCN systems.
Q2: Which systems are compatible with this termination assembly?
A2: It integrates with Honeywell Experion LCN Distributed Control Systems.
Q3: What industries commonly use this assembly?
A3: Industries include chemical processing, power generation, refineries, and water treatment facilities.
Q4: How does it improve system reliability?
A4: It ensures signal integrity and reduces wiring errors across field devices and control modules.
Q5: Is the assembly actively supported by Honeywell?
A5: Yes, it is fully supported under Honeywell’s product lifecycle and maintenance programs.
Q6: What practices help ensure reliable operation?
A6: Proper installation, visual inspections, and maintaining spare assemblies optimize long-term performance.
