Overview
It supports deterministic communication between controllers, I/O subsystems, and operator interfaces across mission-critical industrial environments.
Moreover, this module strengthens system coordination by maintaining stable network performance during continuous process operations.
Automation teams choose this module because it integrates smoothly into existing TDC 3000 and UCN architectures without redesign efforts.
Specification
| Parameter | Description |
|---|---|
| Manufacturer | Honeywell |
| Part Number / Model | 51304685-150 |
| Module Type | Communication Module for UCN |
| Network Standard | Universal Control Network (UCN) for TDC 3000 systems |
| Primary Function | Manages deterministic data exchange between controllers and I/O subsystems |
| Communication Protocols Supported | TCP/IP, MODBUS, CANbus, and legacy UCN token-bus protocols |
| Physical Interfaces | Backplane connection into TDC 3000 chassis plus network interface ports |
| Data Transfer Rate | Supports high-speed network throughput up to 10/100 Mbps |
| Operating Voltage | 24 VDC industrial control power |
| Power Consumption | Low power usage (approx. 1.5 W typical) |
| Operating Temperature | -40 °C to +70 °C for harsh process environments |
| Storage Temperature | -40 °C to +85 °C for non-operating conditions |
| Humidity Tolerance | Designed for industrial humidity ranges (non-condensing) |
| Environmental Protection | Rugged industrial enclosure with environmental ratings (IP67 suggested by some sources) |
| Network Interfaces | RS-485 serial ports, Ethernet/MODBUS channels, auxiliary USB (varies by revision) |
| Performance Features | Deterministic network timing for stable control performance |
| Certification / Compliance | UL and CE compliance typical of industrial automation modules |
| Mounting Method | Rack-mounted into standard Honeywell TDC 3000 control chassis |
| Dimensions (approx.) | Standard rack card form factor for Honeywell controller slots |
| Weight (approx.) | Light industrial module (around 0.14 kg / 0.3 lb) |
| Maintenance Approach | Modular swap for minimized downtime |
| Lifecycle Role | Legacy communication backbone support and lifecycle extension |
FAQ
Q1: What is the primary role of the Honeywell 51304685-150 Communication Module?
It manages reliable data communication between controllers, I/O subsystems, and networks within TDC 3000 systems.
Q2: Is the 51304685-150 compatible with Honeywell UCN architectures?
Yes, it is specifically designed for Universal Control Network communication within TDC 3000 platforms.
Q3: Does replacing this communication module require software configuration changes?
In most installations, technicians can replace the module without modifying existing control logic or settings.
Q4: How does this module support system stability?
Moreover, it maintains deterministic communication timing, which helps ensure predictable control system behavior.
Q5: Is the module suitable for continuous industrial operation?
Yes, it supports continuous duty operation in demanding automation and process control environments.
Q6: Why is this module important for legacy system maintenance?
Therefore, it helps extend the operational life of TDC 3000 systems without requiring complete network upgrades.
