Overview
It converts controller commands into stable output signals that drive field devices in continuous industrial processes.
Moreover, this card supports consistent loop performance, which directly improves process accuracy and operational safety.
Automation engineers choose this card because it integrates easily into existing TDC 3000 installations without control logic changes.
Specification
| Parameter | Description |
|---|---|
| Manufacturer | Honeywell |
| Part Number / Model | 51304672-150 |
| Module Type | Analog Output Card |
| System Compatibility | Honeywell TDC 3000 Distributed Control System |
| Output Channels | 16 analog output channels available for field control |
| Output Signal Types | Voltage (0–10 V) or Current (4–20 mA) configurable per channel |
| Output Resolution | 12-bit resolution ensures fine granularity in signal control |
| Output Accuracy | ±0.1 % of full scale for precise and repeatable analog control |
| Update Rate | Up to ~100 ms per channel for responsive loop adjustments |
| Communication Protocol | UCN interface compatible with Honeywell I/O networks |
| Power Supply | 24 VDC typical automation control power |
| Typical Power Consumption | Depends on configuration and load (standard low-power industrial design) |
| Operating Temperature | Broad industrial range (approx. 0 °C to +60 °C) – consult specific installation guides |
| Storage Temperature | –40 °C to +85 °C for warehouse and non-operational conditions |
| Humidity Rating | 5 % to 95 % RH, non-condensing environments |
| Certifications | CE, UL508, CSA approvals typical of industrial I/O modules |
| Weight | Approx. 0.18 kg / ~0.4 lb industrial card |
| Form Factor | Rack-mountable analog output card for standard Honeywell I/O chassis |
| Country of Origin | USA industrial manufacturing |
FAQ
Q1: What is the main function of the Honeywell 51304672-150 Analog Output Card?
It converts digital control signals into continuous analog outputs for driving industrial field devices.
Q2: Is the 51304672-150 compatible with standard Honeywell TDC 3000 systems?
Yes, it is specifically designed for integration within Honeywell TDC 3000 distributed control platforms.
Q3: Can technicians replace this card without modifying control software?
In most cases, technicians can replace the card directly without changing existing control logic.
Q4: What types of devices does this analog output card typically control?
Moreover, it commonly controls valves, actuators, dampers, and variable-speed drives in process applications.
Q5: Is this card suitable for continuous industrial operation?
Yes, it supports continuous duty operation in demanding automation and process control environments.
Q6: Why is this card important for legacy system maintenance?
Therefore, it helps extend the operational life of TDC 3000 systems without requiring full system replacement.
