Overview
It accurately converts analog and digital signals into actionable data for central controllers.
Moreover, its design ensures reliable communication even in electrically noisy industrial environments.
Control engineers value this interface for high-precision measurement and seamless integration.
Therefore, it is essential for applications requiring consistent signal quality and minimal system latency.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | Honeywell |
| Model Number | 51304516-100 |
| Product Type | Smart Transmitter Interface |
| System Compatibility | TDC 3000 Universal Control Network (UCN) |
| Signal Type | Analog 4–20 mA, HART digital |
| Input Voltage | 24 V DC nominal |
| Power Consumption | 3 W typical |
| Communication Protocols | HART 5/6 compatible, Honeywell proprietary |
| Operating Temperature | 0 °C to 60 °C |
| Storage Temperature | –40 °C to +85 °C |
| Humidity | 5% to 95% non-condensing |
| Dimensions | 180 mm × 120 mm × 30 mm |
| Mounting | Panel or rack-mounted |
| LED Indicators | Power, Status, Communication |
| Certifications | CE, UL, CSA approved |
| Weight | 0.5 kg |
FAQ
Q1: Which systems is the 51304516-100 compatible with?
It is fully compatible with Honeywell TDC 3000 Universal Control Network systems.
Q2: What types of signals does it support?
It supports 4–20 mA analog signals and HART digital communication.
Q3: Can it handle harsh industrial environments?
Yes, it operates reliably in 5%–95% non-condensing humidity and standard temperature ranges.
Q4: Is installation complicated?
In addition, it features plug-and-play compatibility for simple panel or rack mounting.
Q5: Does it provide status or diagnostic feedback?
Yes, LED indicators display power, communication, and operational status.
Q6: What certifications does it hold?
It is CE, UL, and CSA approved for industrial deployment.
