Overview
Moreover, this 3500 Series module continuously measures rod displacement and velocity, enabling early detection of mechanical deviations.
It integrates seamlessly with other 3500 Series protection modules, enhancing reliability and operational safety.
Consequently, engineers can improve equipment lifespan and reduce unplanned downtime in compressors, engines, and pumps.
Specification
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Series | 3500 Machinery Protection System |
| Model Number | 3500/72M 176449-08 |
| Module Type | Reciprocating Rod Position Monitor |
| Monitoring Function | Rod displacement and velocity |
| Number of Channels | 4 rod position channels |
| Input Sensor | Proximity probes and compatible sensors |
| Output | Alarm, trip, and system integration signals |
| Measurement Range | Configurable per application |
| Alarm Types | Alert and danger setpoints |
| Protection Actions | System alarm and trip capabilities |
| System Integration | Compatible with 3500 rack-mounted I/O modules |
| Communication Interface | 3500 system backplane connection |
| Power Supply | Rack-supplied DC power |
| Energy Storage | None |
| Diagnostics | Continuous channel validation and sensor monitoring |
| Operating Environment | Industrial reciprocating machinery |
| Mounting Style | 3500 rack-mounted module |
| Dimensions (H × W × D) | Approx. 241 mm × 99 mm × 241 mm |
| Weight | Approx. 1.4 kg |
| Construction | Industrial-grade electronics with EMI shielding |
FAQ
Yes, the 3500/72M 176449-08 is factory-new and original.
Q2: Is this module available in stock?
Yes, we maintain inventory for immediate orders.
Q3: What is the delivery timeframe?
Delivery typically takes 3 days to 2 weeks depending on order size.
Q4: Which logistics carriers do you use?
We commonly ship via DHL and other reliable carriers.
Q5: Can I return the product if there’s a quality issue?
Yes, returns are supported within 30 days if a quality issue occurs.
