Overview
This 3500 Series Position Monitor Module delivers accurate, low-noise signal processing for industrial machinery protection systems.
Moreover, it integrates seamlessly with existing Bently Nevada 3500 racks, reducing installation complexity and supporting predictive maintenance programs.
Engineers rely on the 3500/45 140072-04 to detect axial movement, shaft misalignment, and other position-related anomalies early.
Consequently, plants experience improved machinery safety, fewer unplanned outages, and extended asset service life.
Specification
| Parameter | Specification |
|---|---|
| Model | 3500/45 140072-04 |
| Manufacturer | Bently Nevada |
| Series | 3500 Machinery Protection Series |
| Module Type | Position Monitor Module |
| Primary Function | Shaft and machinery position signal interfacing, conditioning, and monitoring |
| Supported Sensors | Linear displacement transducers, shaft position sensors, proximity probes, LVDTs |
| Input Signal Type | Analog voltage signals representing absolute or relative position |
| Input Channels | 2–4 independent channels per module (depending on configuration) |
| Channel Architecture | Fully isolated multi-channel design to prevent cross-talk and interference |
| Signal Conditioning | Low-noise analog filtering, amplification, and stabilization for accurate measurement |
| Output Signals | Analog voltage outputs compatible with 3500 Series monitoring modules |
| Backplane Interface | Direct connection to 3500 Series system backplane for power and data communication |
| Power Supply | Supplied via 3500 Series backplane; 5V DC typical operating voltage |
| Energy Storage | Low stored-energy internal design meeting intrinsic safety and reliability standards |
| Rack Compatibility | Standard 3500 Series rack, single-slot width |
| Physical Dimensions (H × W × D) | 241 mm × 24 mm × 99 mm (approximate) |
| Weight | ~0.3 kg |
| Operating Temperature Range | -20°C to +70°C (industrial rated) |
| Humidity Tolerance | Up to 95% non-condensing |
| Environmental Protection | Designed for industrial control cabinet conditions; vibration-resistant |
| Typical Applications | Steam and gas turbines, compressors, generators, pumps, and rotating machinery requiring position monitoring |
| Compliance / Standards | Compatible with Bently Nevada 3500 Series safety and performance standards |
| Installation | Front-access rack-mountable, plug-and-play integration with 3500 system |
