Overview
Specification
| Parameter | Specification | Notes / Details |
|---|---|---|
| Model | 3500/33 149992-01 | Full Bently Nevada part number |
| Series | 3500 Machinery Protection | Compatible with 3500 Series racks |
| Module Type | 16-Channel Relay Output Module | Relay output module for alarms/trips |
| Number of Channels | 16 independent relay outputs | Each channel configurable for alarm or trip |
| Relay Contact Type | SPDT (Single Pole Double Throw) | Provides normally open and normally closed contacts |
| Relay Contact Rating | 2 A @ 30 VDC / 0.5 A @ 125 VAC | Maximum current and voltage per channel |
| Input Voltage | 24 VDC nominal | Operating range: 18–32 VDC |
| Power Consumption | ≤ 6 W typical | Varies depending on relay state |
| Response Time | ≤ 5 ms | Time from input trigger to relay actuation |
| Mounting | 3500 Series Rack Mount | Front-panel or standard 1-slot mount |
| Dimensions | 159 mm H × 25 mm W × 168 mm D | Standard 1-slot width module |
| Weight | 0.8 kg | Lightweight for easy rack integration |
| Operating Temperature | -40°C to 70°C | Continuous industrial operation |
| Storage Temperature | -40°C to 85°C | For transport or spare storage |
| Humidity | 5%–95% non-condensing | IEC 60068-2-30 compliant |
| Shock | 30 g, 11 ms | IEC 60068-2-27 compliant |
| Vibration | 5–500 Hz, 2 g | IEC 60068-2-6 compliant |
| Electrical Isolation | 500 VAC between channels and power | Provides safety and interference protection |
| Status Indicators | LED per channel | Shows relay actuation for monitoring |
| Typical Applications | Machinery protection alarms, trips, interlocks | Turbines, compressors, pumps, motors |
FAQ
A1: Yes, it is fully factory new and genuine Bently Nevada equipment.
Q2: What is the typical shipping time?
A2: Orders ship within 3 days to 2 weeks depending on quantity.
Q3: Which shipping services are available?
A3: Standard carriers include DHL, FedEx, and UPS for worldwide delivery.
Q4: Can this module operate in extreme temperatures?
A4: Yes, it operates between -40°C and 70°C without performance loss.
Q5: Is there a return policy if quality issues occur?
A5: We offer returns within 30 days for products with verified defects.
Q6: Can it integrate with existing 3500 Series racks?
A6: Yes, it is fully compatible with all Bently Nevada 3500 Series racks.
