Overview
Moreover, it ensures accurate event signaling for turbines, compressors, pumps, and other industrial equipment.
Therefore, operators can quickly respond to abnormal conditions, reducing risk and improving operational safety.Designed for the Bently Nevada 3500 Series, the 3500/32-01-01-00 integrates seamlessly with proximity and vibration monitoring modules.
In addition, the module’s deterministic relay logic ensures consistent performance during transient system events.
Specification
| Parameter | Detailed Specification |
|---|---|
| Product Model | 3500/32-01-01-00 |
| Module Type | 4-Channel Relay Module |
| Series | Bently Nevada 3500 Machinery Protection Series |
| Manufacturer | Bently Nevada, a Baker Hughes business |
| Primary Function | Provides four independent relay outputs for alarms and shutdowns |
| Relay Channels | 4 independent channels |
| Relay Contact Type | Dry contact, industrial-rated relays |
| Relay Logic Levels | Alert, Danger, Trip |
| Contact Rating | 2 A at 30 VDC / 0.5 A at 125 VDC (typical) |
| Rack Compatibility | 3500 System Rack |
| Slot Width | Single-slot module |
| Backplane Interface | Standard 3500 series backplane connector |
| Power Supply | Supplied from 3500 rack backplane |
| Power Consumption | Typically <5 W |
| Energy Storage | None, no internal battery or capacitor |
| Operating Temperature | 0°C to +65°C |
| Storage Temperature | –40°C to +85°C |
| Relative Humidity | Up to 95%, non-condensing |
| Physical Height | 241 mm (9.5 in) |
| Physical Width | 24 mm (0.95 in) |
| Physical Depth | 241 mm (9.5 in) |
| Net Weight | Approximately 0.8 kg |
| Typical Applications | Turbines, compressors, pumps, motors, and generators |
| System Role | Machinery protection, alarm signaling, and automated shutdown control |
FAQ
A1: Yes, the 3500/32-01-01-00 is 100% brand new, factory-sealed, and fully genuine Bently Nevada hardware.
A2: Yes, we keep the 3500/32-01-01-00 in stock for immediate order fulfillment.
A3: Shipping typically occurs within 3 days to 2 weeks depending on order quantity.
A4: We commonly ship via DHL and other trusted international express services.
Q5: What is the return policy if a quality issue occurs?
A5: We support returns within 30 days if any quality problem occurs with the 3500/32-01-01-00.
Q6: Can the 3500/32-01-01-00 integrate with existing 3500 system racks?
A6: Yes, it integrates directly with 3500 system racks and monitoring modules without additional modifications.
