Overview
Specification
| Parameter | Specification |
|---|---|
| Model Number | 3500/25-01-05-05 |
| Manufacturer | Bently Nevada |
| Series | 3500 Machinery Protection |
| Module Type | Isolated Keyphasor I/O Module |
| Part Number | 106Mxxxx-01 (specific order-dependent) |
| Input Channels | 2 isolated keyphasor inputs |
| Output Channels | 2 digital output channels for speed/position signals |
| Signal Type | TTL / Sine wave compatible with proximity probes |
| Frequency Range | 0–10 kHz |
| Isolation Voltage | 1500 V between input and output circuits |
| Accuracy | ±0.1° phase angle typical |
| Connectivity | Compatible with 3500 system backplane |
| Mounting | Standard 3500 rack module format |
| Dimensions | 230 mm (L) x 160 mm (W) x 40 mm (H) |
| Weight | 1.4 kg (3.1 lbs) |
| Operating Temperature | -20°C to +70°C (-4°F to +158°F) |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Humidity | 5–95%, non-condensing |
| Power Requirements | Supplied via 3500 system rack, 24 VDC nominal |
| Diagnostic Features | LED indicators for channel status and system health |
| Environmental Rating | Shock-resistant, vibration-resistant, industrial-grade |
FAQ
A1: Yes, it integrates fully with standard Bently Nevada 3500 system racks.
Q2: What is the input signal type?
A2: It accepts TTL or sine-wave keyphasor signals from proximity probes.
Q3: Does it provide electrical isolation between channels?
A3: Yes, each input channel is isolated up to 1500 V from outputs.
Q4: What is the typical operational temperature range?
A4: The module operates from -20°C to +70°C, suitable for industrial environments.
Q5: What is the delivery lead time?
A5: Orders typically ship within 3–14 days depending on order size and logistics.
Q6: Is there a return policy for defective units?
A6: Yes, defective products can be returned within 30 days for quality issues.
